ESFD204M100 SNR  Basic dynamic load rating (C) 12.8 kN Bearing units

ESFD204M100 SNR Basic dynamic load rating (C) 12.8 kN Bearing units

Bearing numberESFD204M100BrandSNRBore Diameter (mm)20d20 mme9.5 mms7.5 mmA17 mmB130.9 mmD233.3 mmH90.5 mmJ71.4 mmL66.5 mmThread (G)M6x1A232.9 mmThread (N1)M10Weight0.4 KgBasic dynamic load rating (C)12.8 kN Cross-reference to other manufacturer's part number VEX /S 75 /S/NS 7CE1 Angular contact ball bearingsBasic static load rating (C0):21.6 kN , W…
Contact Us Now !

Product description

ESFD204M100 SNR Basic dynamic load rating (C) 12.8 kN Bearing units

Bearing numberESFD204M100
BrandSNR
Bore Diameter (mm)20
d20 mm
e9.5 mm
s7.5 mm
A17 mm
B130.9 mm
D233.3 mm
H90.5 mm
J71.4 mm
L66.5 mm
Thread (G)M6x1
A232.9 mm
Thread (N1)M10
Weight0.4 Kg
Basic dynamic load rating (C)12.8 kN

Cross-reference to other manufacturer’s part number

VEX /S 75 /S/NS 7CE1 Angular contact ball bearings

Basic static load rating (C0):21.6 kN , Weight:0.59 Kg , (Grease) Lubrication Speed:19 000 r/min , Db max:110.8 mm , Basic dynamic load rating (C):26 kN
1680207 Deep groove ball bearings

Width :36mm , B:36 mm , d:35 mm , C:21 mm , D:80 mm
TAM 4540 Needle roller bearings

Manufacturer Name:IKO , BDI Inventory:0.0 , Product Group – BDI:B04144 , Minimum Buy Quantity:N/A , Weight / Kilogram:0
S71922 CD/P4A Angular contact ball bearings

Calculation factor f0:16.5 , Mass bearing:0.88 kg , Calculation factor f2D:1.15 , Calculation factor fHC:1
131090/131158X Tapered roller bearings

da:110 mm , R:2.5 mm , Weight:2.08 Kg , F:6.5 mm , Da:137 mm
NP504493/NP949481 Tapered roller bearings

D:104.775 mm , Outer Diameter :104.775mm , Width :30.955mm , d:49.213 mm , B:30.955 mm , Bore Diameter :49.213mm
AST20 18IB12 Plain bearings

ID Chamfer Angle (B deg.):30 , Material:Carbon steel shell with POM plastic liner , OD Chamfer Length (Co):0.045 , ID Chamfer Length (Ci):0.020 , Lube Hole Dia. (dl):0.250
51107 Thrust ball bearings

Weight (g):83.00 , Outer Dia. Pilot (D1):52.0000 , Material:52100 chrome steel. or equivalent. , Max Speed (Oil) (X1000 RPM):5 , Bore Dia. Clearance (d1):37.0000 , Height (H):12.0000
LM12LUU Linear bearings

Basic dynamic load rating (C):0.65 kN , L:57 mm , B:46 mm , Weight:0.08 Kg , W:1.3 mm , D1:20 mm
FYT 55 TF/VA228 Bearing units

Bearing:
YAR 211-2FW/VA228
, Grub (set) screw G2:M10x1 , Basic static load rating C0:29 kN , Hexagonal key size for grub screw N:5 mm , Limiting temperature T max.:350 °C , Attachment bolts, recommended metric size G:16 mm
