EXFC204 SNR L 100 mm  Bearing units

EXFC204 SNR L 100 mm Bearing units

Bearing numberEXFC204BrandSNRBore Diameter (mm)20d20 mmH362 mmA420.5 mme10 mms17 mmA25.5 mmA16 mmB143.5 mmD233.3 mmJ78 mmL100 mmN12 mmThread (G)M6x1A236.5 mmWeight0.7 KgBasic dynamic load rating (C)12.8 kN Cross-reference to other manufacturer's part number USP001S6 Bearing unitsBolt (G):M6 , Basic dynamic load rating (C):5.1 kN , Basic static load…
Contact Us Now !

Product description

EXFC204 SNR L 100 mm Bearing units

Bearing numberEXFC204
BrandSNR
Bore Diameter (mm)20
d20 mm
H362 mm
A420.5 mm
e10 mm
s17 mm
A25.5 mm
A16 mm
B143.5 mm
D233.3 mm
J78 mm
L100 mm
N12 mm
Thread (G)M6x1
A236.5 mm
Weight0.7 Kg
Basic dynamic load rating (C)12.8 kN

Cross-reference to other manufacturer’s part number

USP001S6 Bearing units

Bolt (G):M6 , Basic dynamic load rating (C):5.1 kN , Basic static load rating (C0):4.3 kN , Weight:0.08 Kg
2209K-2RS+H309 Self aligning ball bearings

B2:11 mm , Basic static load rating (C0):10.6 kN , C:23 mm , B1:39 mm , Basic dynamic load rating (C):32.5 kN , Weight:0.548 Kg
SIJK20C Plain bearings

Body End Dia. (d4):34.000 , Body End Flats (W):30.000 , Weight (g):430.00 , Material – Body – Carbon steel-zinc plated, Ball – Hardened chrome steel-chrome plated, Liner:PTFE composite material , Body End Width (l5):10.000
35NQ5528W11 Needle roller bearings

Brand:KOYO , D:55 mm , Bore Diameter :35mm , d:35 mm , Outer Diameter :55mm , Width :28mm
AX 11 140 180 Needle roller bearings

Basic static load rating (C0):770 kN , Weight:0.67 Kg , Basic dynamic load rating (C):111 kN , Eb:145 mm
TL23038CAE4 Spherical roller bearings

Calculation factor (Y2):4.2 , (Oil) Lubrication Speed:1 400 r/min , Calculation factor (Y0):2.8 , (Grease) Lubrication Speed:1 100 r/min , Calculation factor (e):0.24
AST090 10550 Plain bearings

OD Chamfer Length (Co):1.800 , ID Chamfer Angle (B deg.):45 , ID Chamfer Length (Ci):0.600 , Bearing Length Tolerance (B tol.) – +0 / -0.40:+0 / 0.40 , Material:Wrapped bronze with formed lubrication indents. , Bearing Length, Nominal (B):50.000
2TS2-DF0374LLUA1 Angular contact ball bearings

D:46 mm , B:21 mm , Width :21mm , d:17 mm
23220EAW33 Thrust roller bearings

Width :60.300mm , Outer Diameter :180.000mm , H:60.300 mm , d:100.000 mm , D:180.000 mm , Bore Diameter :100.000mm
24192 K30 CW33 Spherical roller bearings

Weight:560 Kg , (Grease) Lubrication Speed:160 r/min , Basic static load rating (C0):14600 kN , Basic dynamic load rating (C):7250 kN
