EXSP202 SNR  L1 225 mm Bearing units

EXSP202 SNR L1 225 mm Bearing units

B34 mmA517 mmd132.4 mmGR1/8" H241 mms130.5 mmS17 mmSW3 mmC12.8 kNC06.65 kNT min.-20 °CT max.100 °CRecommended tightening torque for set screw5.5 NmDesignation of housingSP203-205/47- Designation of bearingEX202G2 Bearing numberEXSP202BrandSNRBore Diameter (mm)15d15 mms17 mmA21 mmB143.5 mmD233.3 mmH78 mmH141 mmL264 mmL1225 mmThread (G)R1/8"We…
Contact Us Now !

Product description

EXSP202 SNR L1 225 mm Bearing units

B34 mm
A517 mm
d132.4 mm
GR1/8″
H241 mm
s130.5 mm
S17 mm
SW3 mm
C12.8 kN
C06.65 kN
T min.-20 °C
T max.100 °C
Recommended tightening torque for set screw5.5 Nm
Designation of housingSP203-205/47-
Designation of bearingEX202G2
Bearing numberEXSP202
BrandSNR
Bore Diameter (mm)15
d15 mm
s17 mm
A21 mm
B143.5 mm
D233.3 mm
H78 mm
H141 mm
L264 mm
L1225 mm
Thread (G)R1/8"
Weight1.8 Kg
Basic dynamic load rating (C)12.8 kN
