EXT209 SNR  Thread (G) M6x1 Bearing units

EXT209 SNR Thread (G) M6x1 Bearing units

A235 mmB42.8 mmA521.4 mmd162 mmGM6x1 H283 mmN249 mms139.7 mmS21.4 mmSW4 mmC31.85 kNC020.8 kNT min.-20 °CT max.100 °CRecommended tightening torque for set screw11.5 NmDesignation of housingT209- Designation of bearingEX209G2 Bearing numberEXT209BrandSNRBore Diameter (mm)45d45 mmL483 mmL519 mmL216 mmL387 mms21.4 mmA49 mmA135 mmB156.3 mmD263.5 mmH11…
Contact Us Now !

Product description

EXT209 SNR Thread (G) M6x1 Bearing units

A235 mm
B42.8 mm
A521.4 mm
d162 mm
GM6x1
H283 mm
N249 mm
s139.7 mm
S21.4 mm
SW4 mm
C31.85 kN
C020.8 kN
T min.-20 °C
T max.100 °C
Recommended tightening torque for set screw11.5 Nm
Designation of housingT209-
Designation of bearingEX209G2
Bearing numberEXT209
BrandSNR
Bore Diameter (mm)45
d45 mm
L483 mm
L519 mm
L216 mm
L387 mm
s21.4 mm
A49 mm
A135 mm
B156.3 mm
D263.5 mm
H117 mm
H183 mm
L144 mm
L145.5 mm
N29 mm
N149 mm
Thread (G)M6x1
J116 mm
J2102 mm
Weight2.5 Kg
Basic dynamic load rating (C)31.85 kN
