EXT212+WB SNR  Basic dynamic load rating (C) 52.5 kN Bearing units

EXT212+WB SNR Basic dynamic load rating (C) 52.5 kN Bearing units

A122 mmB61.8 mmA530.9 mmd182 mmGM6x1 H1130 mmH2102 mmL1119 mmL3102 mmN132 mmN264 mms153.2 mmS30.9 mmC52.5 kNC032.8 kNT min.-20 °CT max.100 °CRecommended tightening torque for set screw22 NmDesignation of housingT212- Designation of bearingEX212G2 Bearing numberEXT212+WBBrandSNRBore Diameter (mm)60d60 mmA4651 mmP300 mme38 mmL2127 mms30.9 mmSW19 mm…
Contact Us Now !

Product description

EXT212+WB SNR Basic dynamic load rating (C) 52.5 kN Bearing units

A1 22 mm
B 61.8 mm
A5 30.9 mm
d1 82 mm
G M6x1
H1 130 mm
H2 102 mm
L1 119 mm
L3 102 mm
N1 32 mm
N2 64 mm
s1 53.2 mm
S 30.9 mm
C 52.5 kN
C0 32.8 kN
T min. -20 °C
T max. 100 °C
Recommended tightening torque for set screw 22 Nm
Designation of housing T212-
Designation of bearing EX212G2
Bearing number EXT212+WB
Brand SNR
Bore Diameter (mm) 60
d 60 mm
A4 651 mm
P 300 mm
e 38 mm
L2 127 mm
s 30.9 mm
SW 19 mm
A 65 mm
B1 77.7 mm
D2 84.2 mm
H 301 mm
J 240 mm
L 568 mm
M 243 mm
M1 22 mm
N 15 mm
T 6 mm
A2 84.8 mm
Weight 20.6 Kg
Basic dynamic load rating (C) 52.5 kN
