F510-4100-H3 Manual Inverter

F510-4100-H3 Manual Inverter

Our mission is to serve our customers as a trusted ally, providing you with the loyalty of a business partner and the economics of an outside vendor. Since many vacuum processes are critical steps in applications, we vow to make sure that our customers have what they need to run their vacuum equipment and processes with maximum efficiency and relia…
Contact Us Now !

Product description

Our mission is to serve our customers as a trusted ally, providing you with the loyalty of a business partner and the economics of an outside vendor. Since many vacuum processes are critical steps in applications, we vow to make sure that our customers have what they need to run their vacuum equipment and processes with maximum efficiency and reliability. We will be there when you need us.if you’re looking for Hydraulic Pumps,Pumps,Hydraulic Motors,Motors,Hydraulic Cylinder,Air Cylinders,Solenoid Valves,Pressure Valves,Check Valves, Flow Valves, Proportional Valves, Filter Elements,Fittings,Gas Claw,Vacuum,Connectors,Components and Accessories,Auto spare parts, then you’ve come to the right place., enable Leader to greatly enhance quality deeply and broadly, and continue towards the top goal; with rigorous and far-reaching quality strategy and perseverance

TECO F510 Series Manual Inverter Nameplate

 photo F510-model1_zps34c9e85a.jpg


TECO F510 Series Manual Inverter Model Code:
 photo F510-model2_zpsc987fa21.jpg



Detailed Parameter

Voltage (Vac) &

Frequency (Hz)

F510 Model

Motor

Power

(Hp)

Applied

Motor

(kW)

Filter

Operator

Protection

Class

(IP55)

with

without

LED

LCD

3ph

380~480V

+10%/-15%

50/60Hz

F510-4005-H3

5

3.7



O

O





F510-4008-H3

7.5

5.5



O

O





F510-4010-H3

10

7.5



O

O





F510-4015-H3

15

11



O

O





F510-4020-H3

20

15



O

O





F510-4030-H3

30

20



O

O





F510-4025-H3

25

18.5



O

O





F510-4040-H3

40

30



O

O





F510-4050-H3

50

37



O

O





F510-4060-H3

60

45



O

O





















F510-4075-H3

75

55



O

O





F510-4100-H3

100

75



O

O





F510-4125-H3

125

94



O

O





F510-4150-H3

150

112



O

O





F510-4175-H3

175

130



O

O





F510-4215-H3

215

160



O

O





F510-4250-H3

250

185



O

O





F510-4300-H3

300

220



O

O





F510-4375-H3

375

280



O

O





F510-4425-H3

425

317



O

O





F510-4535-H3

535

400



O

O





F510-4670-H3

670

500



O

O





F510-4800-H3

800

600



O

O







Notes:

1. Shaded Section: Models currently under Development.

2. Short Circuit Rating: 400V Class: 5KA.

Environment

The environment will directly affect the proper operation and the life span of the inverter. To ensure that the inverter will give maximum service life, please comply with the following environmental conditions:

Protection

Protection

Class

IP20/ NEMA 1, IP00

IP55/ NEMA 12

Ambient Environment

Operating

Temperature

Ambient Temperature: -10°C – +40°C (14 -104 °F)

Without Cover: -10°C – +50°C (14-122 °F)

If several inverters are placed in the same control panel, provide a heat removal means to

maintain ambient temperatures below 40°C

Storage

Temperature

-20°C – +70°C (-4 -158 °F)

Humidity

95% non-condensing

Relative humidity 5% to 95%, free of moisture.

(Follow IEC60068-2-78 standard)

Altitude

< 1000m (3,281 ft.)

Installation

Site

Avoid direct sunlight.

Avoid exposure to rain or moisture.

Avoid oil mist and salinity.

Avoid corrosive liquid and gas.

Avoid dust, lint fibers, and small metal filings.

Avoid electromagnetic interference (soldering machines, power machines).

Keep away from radioactive and flammable materials.

Avoid vibration (stamping, punching machines etc.).

Add a vibration-proof pad if the situation cannot be avoided.

Shock

Maximum acceleration: 1.2G (12m/s²), from 49.84 to 150 Hz

Displacement amplitude : 0.3mm (peak value), from 10 to 49.84 Hz

(Follow IEC60068-2-6 standard)
