FY 3/4 TF SKF Housing material Cast iron  Bearing units

FY 3/4 TF SKF Housing material Cast iron Bearing units

Bearing numberFY 3/4 TFBrandSKFBore Diameter (mm)19.05Width (mm)31d19.05 mms118.3 mmA129.5 mmB31 mmG10 mmJ63.5 mmL86 mmT37.3 mmA211 mmWeight0.61 KgBasic dynamic load rating (C)12.7 kNBasic static load rating (C0)6.55 kNFatigue load limit (Pu)0.28CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogra…
Contact Us Now !

Product description

FY 3/4 TF SKF Housing material Cast iron Bearing units

Bearing numberFY 3/4 TF
BrandSKF
Bore Diameter (mm)19.05
Width (mm)31
d19.05 mm
s118.3 mm
A129.5 mm
B31 mm
G10 mm
J63.5 mm
L86 mm
T37.3 mm
A211 mm
Weight0.61 Kg
Basic dynamic load rating (C)12.7 kN
Basic static load rating (C0)6.55 kN
Fatigue load limit (Pu)0.28
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.59
EAN7316577754820
Product Group – BDIM06110
Number of Mounting Holes4
Mounting MethodSet Screw
Housing Style4 Bolt Square Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts3/8 Inch
RelubricatableYes
Insert Part NumberYAR 204-012-2F
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description4 Bolt Square Flange Block; 3/4" Bore; 3-1/2" Bolt Circle; 2-1/2" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 1-7/32" Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFY 3/4 TF
Weight / LBS1.3
Bore0.75 Inch | 19.05 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round3.5 Inch | 90 Millimeter
Bolt Spacing2.5 Inch | 63.5 Millimeter
Length Thru Bore1.219 Inch | 30.96 Millimeter
Housing materialCast iron
Da68.3 mm
Db157 mm
Db263 mm
A29.5 mm
A111 mm
A33.2 mm
A518.5 mm
N11.5 mm
s118.3 mm
RG1/4-28 UNF
R120.5 mm
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J674 mm
J716 mm
N44 mm
Basic dynamic load rating C12.7 kN
Basic static load rating C06.55 kN
Fatigue load limit Pu0.28 kN
Limiting speed8500 r/min
Mass bearing unit0.55 kg
Thread grub screw G21/4-28 UNF
Hexagonal key size for grub screw N3.175 mm
Recommended tightening torque for grub screw4 N·m
Recommended diameter for attachment bolts, mm G10 mm
Recommended diameter for attachment bolts, inch G0.375 in
Housing
Bearing
End cover
