Home > Bearing units > FY 40 TR SKF Recommended tightening torque for grub screw 6.5 N·m Bearing units
FY 40 TR SKF  Recommended tightening torque for grub screw 6.5 N·m Bearing units

FY 40 TR SKF Recommended tightening torque for grub screw 6.5 N·m Bearing units

Bearing numberFY 40 TRBrandSKFBore Diameter (mm)40d40 mmDa115.9 mms130.2 mmA138.5 mmB49.2 mmG12 mmJ101.5 mmL130 mmN14 mmT54.2 mmA214 mmWeight1.9 KgBasic dynamic load rating (C)30.7 kNBasic static load rating (C0)19 kNFatigue load limit (Pu)0.8CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogram1.…
Contact Us Now !

Product description

FY 40 TR SKF Recommended tightening torque for grub screw 6.5 N·m Bearing units

Bearing numberFY 40 TR
BrandSKF
Bore Diameter (mm)40
d40 mm
Da115.9 mm
s130.2 mm
A138.5 mm
B49.2 mm
G12 mm
J101.5 mm
L130 mm
N14 mm
T54.2 mm
A214 mm
Weight1.9 Kg
Basic dynamic load rating (C)30.7 kN
Basic static load rating (C0)19 kN
Fatigue load limit (Pu)0.8
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram1.83
EAN7316570697056
Product Group – BDIM06110
Number of Mounting Holes4
Mounting MethodSet Screw
Housing Style4 Bolt Square Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts12 Millimeter
RelubricatableYes
Insert Part NumberYAR 208-2RF
SealsMulti Function Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricMetric
Long Description4 Bolt Square Flange Block; 40MM Bore; 144MM Bolt Circle; 101.5MM Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 49.2MM Length Thru Bore; Relubricatable; Multi Function Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFY 40 TR
Weight / LBS4.19
Nominal Bolt Circle Diameter Round5.7 Inch | 144 Millimeter
Bore1.575 Inch | 40 Millimeter
Bolt Spacing3.996 Inch | 101.5 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Length Thru Bore1.937 Inch | 49.2 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Housing materialCast iron
Da115.9 mm
Db198 mm
Db2106 mm
A38.5 mm
A114 mm
A33.2 mm
A523.5 mm
s130.2 mm
RG1/4-28 UNF
R125.5 mm
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J6118 mm
J734 mm
N44 mm
Basic dynamic load rating C30.7 kN
Basic static load rating C019 kN
Fatigue load limit Pu0.8 kN
Limiting speed2800 r/min
Mass bearing unit1.75 kg
Thread grub screw G2M8x1
Hexagonal key size for grub screw N4 mm
Recommended tightening torque for grub screw6.5 N·m
Recommended diameter for attachment bolts, mm G12 mm
Recommended diameter for attachment bolts, inch G0.5 in
Housing
Bearing
End cover
