FY 45 TR SKF Basic dynamic load rating C 33.2 kN Bearing units

Bearing numberFY 45 TRBrandSKFBore Diameter (mm)45d45 mmDa119.1 mms130.2 mmA139 mmB49.2 mmG14 mmJ105 mmL137 mmN16 mmT54.2 mmA214 mmWeight2.1 KgBasic dynamic load rating (C)33.2 kNBasic static load rating (C0)21.6 kNFatigue load limit (Pu)0.915CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogram2.…

Product description

FY 45 TR SKF Basic dynamic load rating C 33.2 kN Bearing units

Bearing number	FY 45 TR
Brand	SKF
Bore Diameter (mm)	45
d	45 mm
Da	119.1 mm
s1	30.2 mm
A1	39 mm
B	49.2 mm
G	14 mm
J	105 mm
L	137 mm
N	16 mm
T	54.2 mm
A2	14 mm
Weight	2.1 Kg
Basic dynamic load rating (C)	33.2 kN
Basic static load rating (C0)	21.6 kN
Fatigue load limit (Pu)	0.915
Category	Flange Block Bearings
BDI Inventory	0.0
Manufacturer Name	SKF
Minimum Buy Quantity	N/A
Weight / Kilogram	2.103
EAN	7316570215380
Product Group – BDI	M06110
Number of Mounting Holes	4
Mounting Method	Set Screw
Housing Style	4 Bolt Square Flange Block
Rolling Element	Ball Bearing
Housing Material	Cast Iron
Expansion / Non-expansion	Non-expansion
Mounting Bolts	14 Millimeter
Relubricatable	Yes
Insert Part Number	YAR 209-2RF
Seals	Multi Function Seal
Housing Configuration	1 Piece Solid
Pilot Configuration	No Pilot
Inch – Metric	Metric
Long Description	4 Bolt Square Flange Block; 45MM Bore; 148MM Bolt Circle; 105MM Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 49.2MM Length Thru Bore; Relubricatable; Multi Function Seal Seals
Other Features	Single Row \| Standard Duty \| Wide Inner Race \| Open End \| Has Flinger \| Y Bearing
Category – BDI	Flange Block
UNSPSC	31171501
Harmonized Tariff Code	8483.20.40.40
Noun	Bearing
Keyword String	Flanged
Manufacturer URL	http://www.skf.com
Manufacturer Item Number	FY 45 TR
Weight / LBS	4.63
Bore	1.772 Inch \| 45 Millimeter
Cartridge Pilot Depth	0 Inch \| 0 Millimeter
Bolt Spacing	4.134 Inch \| 105 Millimeter
Nominal Bolt Circle Diameter Round	5.8 Inch \| 148 Millimeter
Cartridge Pilot Diameter	0 Inch \| 0 Millimeter
Length Thru Bore	1.937 Inch \| 49.2 Millimeter
Housing material	Cast iron
D_a	119.1 mm
D_b1	102 mm
D_b2	112 mm
A	39 mm
A₁	14 mm
A₃	3.2 mm
A₅	23 mm
s₁	30.2 mm
R_G	1/4-28 UNF
R₁	24.5 mm
D_N	6.5 mm
SW_N	7 mm
G_N	1/4-28 SAE-LT
J₆	123 mm
J₇	33.5 mm
N₄	4 mm
Basic dynamic load rating C	33.2 kN
Basic static load rating C₀	21.6 kN
Fatigue load limit P_u	0.915 kN
Limiting speed	2400 r/min
Mass bearing unit	1.9 kg
Thread grub screw G₂	M8x1
Hexagonal key size for grub screw N	4 mm
Recommended tightening torque for grub screw	6.5 N·m
Recommended diameter for attachment bolts, mm G	14 mm
Recommended diameter for attachment bolts, inch G	0.5625 in
Housing	FY 509 M
Bearing	YAR 209-2RF
End cover	ECY 209
