FY 60 TR SKF overall length/diameter: 175 mm  Bearing units

FY 60 TR SKF overall length/diameter: 175 mm Bearing units

Bearing numberFY 60 TRBrandSKFBore Diameter (mm)60d60 mmDa161.9 mms139.7 mmA152 mmB65.1 mmG16 mmJ143 mmL175 mmN18 mmT73.7 mmA217 mmWeight4.6 KgBasic dynamic load rating (C)52.7 kNBasic static load rating (C0)36 kNFatigue load limit (Pu)1.53CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogram4.229…
Contact Us Now !

Product description

FY 60 TR SKF overall length/diameter: 175 mm Bearing units

Bearing numberFY 60 TR
BrandSKF
Bore Diameter (mm)60
d60 mm
Da161.9 mm
s139.7 mm
A152 mm
B65.1 mm
G16 mm
J143 mm
L175 mm
N18 mm
T73.7 mm
A217 mm
Weight4.6 Kg
Basic dynamic load rating (C)52.7 kN
Basic static load rating (C0)36 kN
Fatigue load limit (Pu)1.53
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram4.229
EAN7316570504309
Product Group – BDIM06110
Number of Mounting Holes4
Mounting MethodSet Screw
Housing Style4 Bolt Square Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts16 Millimeter
RelubricatableYes
Insert Part NumberYAR 212-2RF
SealsMulti Function Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricMetric
Long Description4 Bolt Square Flange Block; 60MM Bore; 202MM Bolt Circle; 143MM Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 65.09MM Length Thru Bore; Relubricatable; Multi Function Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFY 60 TR
Weight / LBS10.1
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Bolt Spacing5.63 Inch | 143 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Bore2.362 Inch | 60 Millimeter
Nominal Bolt Circle Diameter Round8 Inch | 202 Millimeter
Length Thru Bore2.563 Inch | 65.09 Millimeter
bore diameter:60 mm
radial static load capacity:36 kN
bolt center-to-center length:143 mm
length through bore:73.7 mm
overall length/diameter:175 mm
finish/coating:Uncoated
bore type:Round
maximum rpm:1800 RPM
mounting type:Four-Bolt Flange
lubrication type:Lubrication Fitting
housing material:Cast Iron
series:FY
locking device:Set Screw
replacement bearing:YAR 212-2RF
expansion type:Non-Expansion Bearing (Fixed)
manufacturer upc number:7316570504309
radial dynamic load capacity:52.7 kN
Housing materialCast iron
Da161.9 mm
Db1130 mm
Db2143 mm
A52 mm
A117 mm
A33.2 mm
A535.5 mm
s139.7 mm
RG1/4-28 UNF
R134.5 mm
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J6161 mm
J749.5 mm
N44 mm
Basic dynamic load rating C52.7 kN
Basic static load rating C036 kN
Fatigue load limit Pu1.53 kN
Limiting speed1800 r/min
Mass bearing unit3.85 kg
Thread grub screw G2M10x1
Hexagonal key size for grub screw N5 mm
Recommended tightening torque for grub screw16.5 N·m
Recommended diameter for attachment bolts, mm G16 mm
Recommended diameter for attachment bolts, inch G0.625 in
Housing
Bearing
End cover
