Home > Bearing units > FYJ 50 TF SKF 50x40x15mm Recommended diameter for attachment bolts, mm G 14 mm Bearing units
FYJ 50 TF SKF 50x40x15mm  Recommended diameter for attachment bolts, mm G 14 mm Bearing units

FYJ 50 TF SKF 50x40x15mm Recommended diameter for attachment bolts, mm G 14 mm Bearing units

Bearing numberFYJ 50 TFSize (mm)50x40x15BrandSKFBore Diameter (mm)50Outer Diameter (mm)40Width (mm)15d50 mmA40 mmA115 mmA3 - H143.2 mmB51.6 mmDa - H11125.4 mmDb1116 mmDb2118 mmJ111 mmL143 mmH16 mms132.6 mmT54.6 mmJ6129 mmJ735.5 mmN44 mmDN6.5 mmSWN7 mmGN - 1/4-28 SAE-LT1/428 SAELTRG - 1/4-28 UNF1/428 UNFR122 mmBasic dynamic load rating - C35.1 kNBas…
Contact Us Now !

Product description

FYJ 50 TF SKF 50x40x15mm Recommended diameter for attachment bolts, mm G 14 mm Bearing units

Bearing numberFYJ 50 TF
Size (mm)50x40x15
BrandSKF
Bore Diameter (mm)50
Outer Diameter (mm)40
Width (mm)15
d50 mm
A40 mm
A115 mm
A3 – H143.2 mm
B51.6 mm
Da – H11125.4 mm
Db1116 mm
Db2118 mm
J111 mm
L143 mm
H16 mm
s132.6 mm
T54.6 mm
J6129 mm
J735.5 mm
N44 mm
DN6.5 mm
SWN7 mm
GN – 1/4-28 SAE-LT1/428 SAELT
RG – 1/4-28 UNF1/428 UNF
R122 mm
Basic dynamic load rating – C35.1 kN
Basic static load rating – C023.2 kN
Fatigue load limit – Pu0.98 kN
Limiting speed4000 r/min
Mass bearing unit2.35 kg
Thread – G2M10x1
Hexagonal key size for grub screw – H5 mm
CategoryMounted Units & Inserts
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram2.596
EAN7316571006765
Product Group – BDIM06110
bore diameter:50 mm
radial dynamic load capacity:35.1 kN
bolt center-to-center length:111 mm
radial static load capacity:23.2 kN
overall length/diameter:143 mm
length through bore:51.6 mm
overall height:54.6 mm
finish/coating:Blue Alkyd/Acryl Paint (RAL 5007)
bore type:Round
bolt size:16 mm
mounting type:Four-Bolt Flange
maximum rpm:4000 rpm
housing material:Cast Iron
lubrication type:Lubrication Fitting
locking device:Set Screw
series:FYJ
expansion type:Non-Expansion Bearing (Fixed)
manufacturer product page:Click here
bearing material:Steel
manufacturer upc number:7316571006765
Housing materialCast iron
Da125.4 mm
Db1116 mm
Db2118 mm
A115 mm
A33.2 mm
N16 mm
s132.6 mm
RG1/4-28 UNF
R122 mm
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J6129 mm
J735.5 mm
N44 mm
Basic dynamic load rating C35.1 kN
Basic static load rating C023.2 kN
Fatigue load limit Pu0.98 kN
Thread grub screw G2M10x1
Hexagonal key size for grub screw N5 mm
Recommended tightening torque for grub screw16.5 N·m
Recommended diameter for attachment bolts, mm G14 mm
Recommended diameter for attachment bolts, inch G0.5625 in
Housing
Bearing
