Home > Bearing units > FYM 1.15/16 TF SKF Weight 4 Kg Bearing units
FYM 1.15/16 TF SKF Weight 4 Kg  Bearing units

FYM 1.15/16 TF SKF Weight 4 Kg Bearing units

Bearing numberFYM 1.15/16 TFBrandSKFBore Diameter (mm)49.213Width (mm)55.6d49.213 mms133.4 mmA147.5 mmB55.6 mmG16 mmJ130 mmL162 mmT64.4 mmA216 mmWeight4 KgBasic dynamic load rating (C)43.6 kNBasic static load rating (C0)29 kNFatigue load limit (Pu)1.25CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / K…
Contact Us Now !

Product description

FYM 1.15/16 TF SKF Weight 4 Kg Bearing units

Bearing numberFYM 1.15/16 TF
BrandSKF
Bore Diameter (mm)49.213
Width (mm)55.6
d49.213 mm
s133.4 mm
A147.5 mm
B55.6 mm
G16 mm
J130 mm
L162 mm
T64.4 mm
A216 mm
Weight4 Kg
Basic dynamic load rating (C)43.6 kN
Basic static load rating (C0)29 kN
Fatigue load limit (Pu)1.25
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram3.81
EAN7316577755155
Product Group – BDIM06110
Number of Mounting Holes4
Mounting MethodSet Screw
Housing Style4 Bolt Square Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts5/8 Inch
RelubricatableYes
Insert Part NumberYAR 211-115-2F
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description4 Bolt Square Flange Block; 1-15/16" Bore; 7.2" Bolt Circle; 5.118" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 2-3/16" Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Medium Duty | Wide Inner Race | Open End | Has Flinger
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYM 1.15/16 TF
Weight / LBS8.38
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Bolt Spacing5.118 Inch | 130 Millimeter
Bore1.938 Inch | 49.225 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round7.2 Inch | 184 Millimeter
Length Thru Bore2.189 Inch | 55.6 Millimeter
