FYR 3 SKF 76.2×111.125×73.025mm  series: 222 Bearing units

FYR 3 SKF 76.2×111.125×73.025mm series: 222 Bearing units

Bearing numberFYR 3Size (mm)76.2x111.125x73.025BrandSKFBore Diameter (mm)76.2Outer Diameter (mm)111.125Width (mm)73.025da76.2 mmd2111.125 mmA73.025 mmA197.631 mmA330.162 mmA537.306 mmA623.812 mmB92.075 mma6.35 mmJ200.025 mmL241.3 mmN120.638 mms31.75 mmS0.794 mmBasic dynamic load rating - C158 kNLimiting speed2800 r/minCategoryFlange Block BearingsB…
Contact Us Now !

Product description

FYR 3 SKF 76.2×111.125×73.025mm series: 222 Bearing units

Bearing numberFYR 3
Size (mm)76.2×111.125×73.025
BrandSKF
Bore Diameter (mm)76.2
Outer Diameter (mm)111.125
Width (mm)73.025
da76.2 mm
d2111.125 mm
A73.025 mm
A197.631 mm
A330.162 mm
A537.306 mm
A623.812 mm
B92.075 mm
a6.35 mm
J200.025 mm
L241.3 mm
N120.638 mm
s31.75 mm
S0.794 mm
Basic dynamic load rating – C158 kN
Limiting speed2800 r/min
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram11.8
EAN7316576664342
Product Group – BDIM06288
Number of Mounting Holes4
Mounting MethodConcentric Collar
Housing Style4 Bolt Round Flange Block
Rolling ElementSpherical Roller Bearing
Housing MaterialCast Iron
Expansion / Non-expansionExpansion
Mounting Bolts3/4 Inch
RelubricatableYes
Insert Part Number22215
SealsTrigard
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description4 Bolt Round Flange Block; 3" Bore; 7.9" Bolt Circle; 5.6" Bolt Spacing; 1 Piece Solid; Concentric Collar Mount; Cast Iron; Spherical Roller Bearing; 3-5/8" Length Thru Bore; Relubricatable; Trigard Seals
Other FeaturesDouble Row | Heavy Duty | Open End | With Set Screw
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.80
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYR 3
Weight / LBS26
Length Thru Bore3.625 Inch | 92.075 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round7.9 Inch | 200 Millimeter
Bolt Spacing5.6 Inch | 141.4 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Bore3 Inch | 76.2 Millimeter
bore diameter:3 in
locking device:Set Screw
bolt center-to-center length:7.8750 in
expansion type:Non-Expansion Bearing (Fixed)
bolt circle diameter:7-7/8 in
seal type:Contact/Lip
overall length/diameter:9.2500 in
overall depth:3-7/8 in
flange mounting type:Four-Bolt Round
radial dynamic load capacity:35500 lb
bearing type:Spherical Roller
radial static load capacity:46800 lb
housing construction:Solid Flange Mount
operating temperature range:Maximum of +110 °F
bore type:Round
finish/coating:Uncoated
duty type:Standard Duty
lubrication type:Lubrication Fitting
housing material:Cast Iron
series:222
da76.2 mm
d2111.125 mm
A197.631 mm
A330.163 mm
A537.306 mm
A623.813 mm
N120.637 mm
Basic dynamic load rating C158 kN
Mass bearing unit11.8 kg
Attachment bolt diameter G19.05 mm
