FYT 1.3/16 RM SKF  Mounting Bolts 7/16 Inch Bearing units

FYT 1.3/16 RM SKF Mounting Bolts 7/16 Inch Bearing units

Bearing numberFYT 1.3/16 RMBrandSKFBore Diameter (mm)30.163Width (mm)31d30.163 mms122 mmA132.5 mmB31 mmG10 mmH141.5 mmJ116.9 mmL83 mmN12.7 mmT42.2 mmA213 mmWeight0.88 KgBasic dynamic load rating (C)19.5 kNBasic static load rating (C0)11.2 kNFatigue load limit (Pu)0.475CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy Quan…
Contact Us Now !

Product description

FYT 1.3/16 RM SKF Mounting Bolts 7/16 Inch Bearing units

Bearing numberFYT 1.3/16 RM
BrandSKF
Bore Diameter (mm)30.163
Width (mm)31
d30.163 mm
s122 mm
A132.5 mm
B31 mm
G10 mm
H141.5 mm
J116.9 mm
L83 mm
N12.7 mm
T42.2 mm
A213 mm
Weight0.88 Kg
Basic dynamic load rating (C)19.5 kN
Basic static load rating (C0)11.2 kN
Fatigue load limit (Pu)0.475
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.82
Product Group – BDIM06110
Number of Mounting Holes2
Mounting MethodSet Screw
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts7/16 Inch
RelubricatableYes
Insert Part NumberYAT 206-103
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description2 Bolt Flange Block; 1-3/16" Bore; 4.6" Bolt Circle; 4-19/32" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 1-7/32" Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Narrow Inner Race | Open End | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYT 1.3/16 RM
Weight / LBS1.8
Cartridge Pilot Depth0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round4.6 Inch | 117 Millimeter
Length Thru Bore1.219 Inch | 30.96 Millimeter
Bolt Spacing4.594 Inch | 116.7 Millimeter
Bore1.188 Inch | 30.175 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
