Home > Bearing units > FYT 1.3/8 FM SKF H 130.2 mm Bearing units
FYT 1.3/8 FM SKF  H 130.2 mm Bearing units

FYT 1.3/8 FM SKF H 130.2 mm Bearing units

Bearing numberFYT 1.3/8 FMBrandSKFBore Diameter (mm)34.925d34.925 mmDa156 mms150.4 mmA134.5 mmB138.9 mmG29.4 mmH130.2 mmJ96 mmL14.3 mmN12 mmT25.5 mmA213 mmWeight1.35 KgBasic dynamic load rating (C)15.3 kNBasic static load rating (C0)0.655 kNCategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogram1.36…
Contact Us Now !

Product description

FYT 1.3/8 FM SKF H 130.2 mm Bearing units

Bearing numberFYT 1.3/8 FM
BrandSKF
Bore Diameter (mm)34.925
d34.925 mm
Da156 mm
s150.4 mm
A134.5 mm
B138.9 mm
G29.4 mm
H130.2 mm
J96 mm
L14.3 mm
N12 mm
T25.5 mm
A213 mm
Weight1.35 Kg
Basic dynamic load rating (C)15.3 kN
Basic static load rating (C0)0.655 kN
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram1.36
EAN7316576614644
Product Group – BDIM06110
Number of Mounting Holes2
Mounting MethodEccentric Collar
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts1/2 Inch
RelubricatableYes
Insert Part NumberYET 207-106
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description2 Bolt Flange Block; 1-3/8" Bore; 5.1" Bolt Circle; 5-1/8" Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Iron; Ball Bearing; 1-17/32" Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Narrow Inner Race | Open End | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYT 1.3/8 FM
Weight / LBS3
Cartridge Pilot Depth0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round5.1 Inch | 130 Millimeter
Length Thru Bore1.531 Inch | 38.9 Millimeter
Bore1.375 Inch | 34.925 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Bolt Spacing5.125 Inch | 130.18 Millimeter
