Home > Bearing units > FYT 1/2 TF SKF Harmonized Tariff Code 8483.20.40.40 Bearing units
FYT 1/2 TF SKF  Harmonized Tariff Code 8483.20.40.40 Bearing units

FYT 1/2 TF SKF Harmonized Tariff Code 8483.20.40.40 Bearing units

Bearing numberFYT 1/2 TFBrandSKFBore Diameter (mm)12.7Width (mm)27.4d12.7 mms115.9 mmA123.4 mmB27.4 mmG10 mmH98.5 mmJ76.2 mmL54 mmN11.1 mmT30.6 mmA211.5 mmWeight0.33 KgBasic dynamic load rating (C)9.56 kNBasic static load rating (C0)4.75 kNFatigue load limit (Pu)0.2CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy Quantit…
Contact Us Now !

Product description

FYT 1/2 TF SKF Harmonized Tariff Code 8483.20.40.40 Bearing units

Bearing number FYT 1/2 TF
Brand SKF
Bore Diameter (mm) 12.7
Width (mm) 27.4
d 12.7 mm
s1 15.9 mm
A1 23.4 mm
B 27.4 mm
G 10 mm
H 98.5 mm
J 76.2 mm
L 54 mm
N 11.1 mm
T 30.6 mm
A2 11.5 mm
Weight 0.33 Kg
Basic dynamic load rating (C) 9.56 kN
Basic static load rating (C0) 4.75 kN
Fatigue load limit (Pu) 0.2
Category Flange Block Bearings
BDI Inventory 0.0
Manufacturer Name SKF
Minimum Buy Quantity N/A
Weight / Kilogram 0.32
EAN 7316577755186
Product Group – BDI M06110
Number of Mounting Holes 2
Mounting Method Set Screw
Housing Style 2 Bolt Flange Block
Rolling Element Ball Bearing
Housing Material Cast Iron
Expansion / Non-expansion Non-expansion
Mounting Bolts 3/8 Inch
Relubricatable Yes
Insert Part Number YAR 203-008-2F
Seals M Seal
Housing Configuration 1 Piece Solid
Pilot Configuration No Pilot
Inch – Metric Inch
Long Description 2 Bolt Flange Block; 1/2" Bore; 3" Bolt Circle; 3" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 1-3/32" Length Thru Bore; Relubricatable; M Seal Seals
Other Features Single Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDI Flange Block
UNSPSC 31171501
Harmonized Tariff Code 8483.20.40.40
Noun Bearing
Keyword String Flanged
Manufacturer URL http://www.skf.com
Manufacturer Item Number FYT 1/2 TF
Weight / LBS 0.7
Cartridge Pilot Diameter 0 Inch | 0 Millimeter
Bore 0.5 Inch | 12.7 Millimeter
Cartridge Pilot Depth 0 Inch | 0 Millimeter
Length Thru Bore 1.094 Inch | 27.8 Millimeter
Nominal Bolt Circle Diameter Round 3 Inch | 76 Millimeter
Bolt Spacing 3 Inch | 76.2 Millimeter
