FYT 2. TF/VA228 SKF 47.63×50.8×20.64mm  seal type: Contact Seal Bearing units

FYT 2. TF/VA228 SKF 47.63×50.8×20.64mm seal type: Contact Seal Bearing units

Bearing numberFYT 2. TF/VA228Size (mm)47.63x50.8x20.64BrandSKFBore Diameter (mm)47.63Outer Diameter (mm)50.8Width (mm)20.64d50.8 mmA147.63 mmA220.64 mmJ184.15 mmH215.9 mmL127 mmT69 mmH19 mmB55.6 mms133.4 mmBasic dynamic load rating - C43.6 kNBasic static load rating - C029 kNLimiting speed110 r/minLimiting temperature - T350 °CMass bearing unit…
Contact Us Now !

Product description

FYT 2. TF/VA228 SKF 47.63×50.8×20.64mm seal type: Contact Seal Bearing units

Bearing numberFYT 2. TF/VA228
Size (mm)47.63×50.8×20.64
BrandSKF
Bore Diameter (mm)47.63
Outer Diameter (mm)50.8
Width (mm)20.64
d50.8 mm
A147.63 mm
A220.64 mm
J184.15 mm
H215.9 mm
L127 mm
T69 mm
H19 mm
B55.6 mm
s133.4 mm
Basic dynamic load rating – C43.6 kN
Basic static load rating – C029 kN
Limiting speed110 r/min
Limiting temperature – T350 °C
Mass bearing unit3.45 kg
Grub (set) screw – G2 – 3/8-24 UNF3/824 UNF
Hexagonal key size for grub screw – H4.762 mm
Recommended tightening torque for grub screw16.5 N·m
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram3.345
EAN7316571737058
Product Group – BDIM06110
Number of Mounting Holes2
Mounting MethodSet Screw
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts5/8 Inch
RelubricatableYes
Insert Part NumberYAR 211-200-2FW/VA228
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description2 Bolt Flange Block; 2" Bore; 7.3" Bolt Circle; 7-1/4" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 2-3/16" Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | High Temperature Bearing with Graphite | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYT 2. TF/VA228
Weight / LBS6.6
Nominal Bolt Circle Diameter Round7.3 Inch | 184.2 Millimeter
Bore2 Inch | 50.8 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Bolt Spacing7.25 Inch | 184.15 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Length Thru Bore2.188 Inch | 55.575 Millimeter
bore diameter:2.0000 in
radial static load capacity:6530 lbf
bolt center-to-center length:184.2 mm
seal type:Contact Seal
overall length/diameter:127 mm
length through bore:62.8 mm
bore type:Round
operating temperature range:-30 to +120 °F
mounting type:Two-Bolt Flange
finish/coating:Uncoated
housing material:Cast Iron
lubrication type:Cannot Be Relubricated
locking device:Set Screw
series:FYT
expansion type:Non-Expansion Bearing (Fixed)
manufacturer upc number:7316571737058
A147.63 mm
A220.64 mm
N19 mm
s133.4 mm
Basic dynamic load rating C43.6 kN
Basic static load rating C029 kN
Limiting temperature T max.350 °C
Grub (set) screw G23/8-24 UNF
Hexagonal key size for grub screw N4.763 mm
Attachment bolts, recommended metric size G16 mm
