FYTB 20 FM SKF Rolling Element Ball Bearing  Bearing units

FYTB 20 FM SKF Rolling Element Ball Bearing Bearing units

Bearing numberFYTB 20 FMBrandSKFBore Diameter (mm)20d20 mmDa50.8 mms123.5 mmA129.5 mmB131 mmG10 mmH112 mmJ90 mmL60.5 mmN11.5 mmT42.5 mmA211 mmWeight0.52 KgBasic dynamic load rating (C)12.7 kNBasic static load rating (C0)6.55 kNFatigue load limit (Pu)0.28CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight /…
Contact Us Now !

Product description

FYTB 20 FM SKF Rolling Element Ball Bearing Bearing units

Bearing numberFYTB 20 FM
BrandSKF
Bore Diameter (mm)20
d20 mm
Da50.8 mm
s123.5 mm
A129.5 mm
B131 mm
G10 mm
H112 mm
J90 mm
L60.5 mm
N11.5 mm
T42.5 mm
A211 mm
Weight0.52 Kg
Basic dynamic load rating (C)12.7 kN
Basic static load rating (C0)6.55 kN
Fatigue load limit (Pu)0.28
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.52
EAN7316577041098
Product Group – BDIM06110
Number of Mounting Holes2
Mounting MethodEccentric Collar
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts10 Millimeter
RelubricatableYes
Insert Part NumberYET 204
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricMetric
Long Description2 Bolt Flange Block; 20MM Bore; 90MM Bolt Circle; 90MM Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Iron; Ball Bearing; 31MM Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Narrow Inner Race | Open End | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYTB 20 FM
Weight / LBS1.15
Bore0.787 Inch | 20 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Bolt Spacing3.543 Inch | 90 Millimeter
Nominal Bolt Circle Diameter Round3.5 Inch | 90 Millimeter
Length Thru Bore1.22 Inch | 31 Millimeter
bore diameter:20 mm
radial static load capacity:6.55 kN
bolt center-to-center length:90 mm
seal type:Contact with Flinger
overall length/diameter:60.5 mm
length through bore:42.5 mm
bore type:Round
finish/coating:Uncoated
mounting type:Two-Bolt Flange
maximum rpm:8500 RPM
housing material:Cast Iron
lubrication type:Lubrication Fitting
locking device:Eccentric Collar
series:FYTB
expansion type:Non-Expansion Bearing (Fixed)
replacement bearing:YET 204
radial dynamic load capacity:12.7 kN
manufacturer upc number:7316577041098
Housing materialCast iron
Da50.8 mm
Db158 mm
Db260.5 mm
A29.5 mm
A111 mm
A33.2 mm
A518.5 mm
B131 mm
B44.75 mm
s124 mm
RG1/4-28 UNF
R120 mm
Rα45 °
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J674 mm
J711.5 mm
N42 mm
Basic dynamic load rating C12.7 kN
Basic static load rating C06.55 kN
Fatigue load limit Pu0.28 kN
Limiting speed8500 r/min
Mass bearing unit0.47 kg
Thread grub screw G2M6x0.75
Hexagonal key size for grub screw N3 mm
Recommended tightening torque for grub screw4 N·m
Recommended diameter for attachment bolts, mm G10 mm
Recommended diameter for attachment bolts, inch G0.375 in
Housing
Bearing
End cover
