FYTB 25 FM SKF  Basic dynamic load rating C 14 kN Bearing units

FYTB 25 FM SKF Basic dynamic load rating C 14 kN Bearing units

Bearing numberFYTB 25 FMBrandSKFBore Diameter (mm)25d25 mmDa63.5 mms123.5 mmA130 mmB131 mmG10 mmH124 mmJ99 mmL70 mmN11.5 mmT42.5 mmA212 mmWeight0.64 KgBasic dynamic load rating (C)14 kNBasic static load rating (C0)7.8 kNFatigue load limit (Pu)0.335CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilog…
Contact Us Now !

Product description

FYTB 25 FM SKF Basic dynamic load rating C 14 kN Bearing units

Bearing numberFYTB 25 FM
BrandSKF
Bore Diameter (mm)25
d25 mm
Da63.5 mm
s123.5 mm
A130 mm
B131 mm
G10 mm
H124 mm
J99 mm
L70 mm
N11.5 mm
T42.5 mm
A212 mm
Weight0.64 Kg
Basic dynamic load rating (C)14 kN
Basic static load rating (C0)7.8 kN
Fatigue load limit (Pu)0.335
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.64
EAN7316571047737
Product Group – BDIM06110
Number of Mounting Holes2
Mounting MethodEccentric Collar
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts10 Millimeter
RelubricatableYes
Insert Part NumberYET 205
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricMetric
Long Description2 Bolt Flange Block; 25MM Bore; 99MM Bolt Circle; 99MM Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Iron; Ball Bearing; 31MM Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Narrow Inner Race | Open End | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYTB 25 FM
Weight / LBS1.41
Length Thru Bore1.22 Inch | 31 Millimeter
Nominal Bolt Circle Diameter Round3.9 Inch | 99 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Bore0.984 Inch | 25 Millimeter
Bolt Spacing3.9 Inch | 99 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
bore diameter:25 mm
radial static load capacity:7.8 kN
bolt center-to-center length:99 mm
seal type:Contact with Flinger
overall length/diameter:70 mm
length through bore:42.5 mm
bore type:Round
finish/coating:Uncoated
mounting type:Two-Bolt Flange
maximum rpm:7000 RPM
housing material:Cast Iron
lubrication type:Lubrication Fitting
locking device:Eccentric Collar
series:FYTB
expansion type:Non-Expansion Bearing (Fixed)
replacement bearing:YET 205
radial dynamic load capacity:14 kN
manufacturer upc number:7316571047737
Housing materialCast iron
Da63.5 mm
Db165 mm
Db270 mm
A30 mm
A112 mm
A33.2 mm
A518 mm
B131 mm
B44.75 mm
s123.5 mm
RG1/4-28 UNF
R120.5 mm
Rα45 °
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J681 mm
J712 mm
N42 mm
Basic dynamic load rating C14 kN
Basic static load rating C07.8 kN
Fatigue load limit Pu0.335 kN
Limiting speed7000 r/min
Mass bearing unit0.57 kg
Thread grub screw G2M6x0.75
Hexagonal key size for grub screw N3 mm
Recommended tightening torque for grub screw4 N·m
Recommended diameter for attachment bolts, mm G10 mm
Recommended diameter for attachment bolts, inch G0.375 in
Housing
Bearing
End cover
