FYTB 30 TF SKF Recommended diameter for attachment bolts, mm G 10 mm  Bearing units

FYTB 30 TF SKF Recommended diameter for attachment bolts, mm G 10 mm Bearing units

Bearing numberFYTB 30 TFBrandSKFBore Diameter (mm)30d30 mmDa76.2 mms122.2 mmA132.5 mmB38.1 mmG10 mmH141.5 mmJ116.5 mmL83 mmN11.5 mmT42.2 mmA213 mmWeight0.93 KgBasic dynamic load rating (C)19.5 kNBasic static load rating (C0)11.2 kNFatigue load limit (Pu)0.475CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWei…
Contact Us Now !

Product description

FYTB 30 TF SKF Recommended diameter for attachment bolts, mm G 10 mm Bearing units

Bearing numberFYTB 30 TF
BrandSKF
Bore Diameter (mm)30
d30 mm
Da76.2 mm
s122.2 mm
A132.5 mm
B38.1 mm
G10 mm
H141.5 mm
J116.5 mm
L83 mm
N11.5 mm
T42.2 mm
A213 mm
Weight0.93 Kg
Basic dynamic load rating (C)19.5 kN
Basic static load rating (C0)11.2 kN
Fatigue load limit (Pu)0.475
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.93
EAN7316577030993
Product Group – BDIM06110
Number of Mounting Holes2
Mounting MethodSet Screw
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts10 Millimeter
RelubricatableYes
Insert Part NumberYAR 206-2F
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricMetric
Long Description2 Bolt Flange Block; 30MM Bore; 117MM Bolt Circle; 116.5MM Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 38.1MM Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYTB 30 TF
Weight / LBS2.05
Bore1.181 Inch | 30 Millimeter
Bolt Spacing4.587 Inch | 116.5 Millimeter
Length Thru Bore1.5 Inch | 38.1 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round4.6 Inch | 117 Millimeter
bore diameter:30 mm
radial static load capacity:11.2 kN
bolt center-to-center length:116.50 mm
seal type:Contact with Flinger
overall length/diameter:83 mm
length through bore:42.2 mm
bore type:Round
operating temperature range:Maximum of +110 °F
duty type:Standard Duty
finish/coating:Uncoated
mounting type:Two-Bolt Flange
maximum rpm:6300 RPM
housing material:Cast Iron
lubrication type:Lubrication Fitting
locking device:Set Screw
series:FYTB
expansion type:Non-Expansion Bearing (Fixed)
replacement bearing:YAR 206-2F
radial dynamic load capacity:19.5 kN
manufacturer upc number:7316577030993
Housing materialCast iron
Da76.2 mm
Db177 mm
Db283 mm
A32.5 mm
A113 mm
A33.2 mm
A520 mm
B45 mm
s122.2 mm
RG1/4-28 UNF
R121 mm
Rα45 °
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J698.5 mm
J712.5 mm
N42 mm
Basic dynamic load rating C19.5 kN
Basic static load rating C011.2 kN
Fatigue load limit Pu0.475 kN
Limiting speed6300 r/min
Mass bearing unit0.84 kg
Thread grub screw G2M6x0.75
Hexagonal key size for grub screw N3 mm
Recommended tightening torque for grub screw4 N·m
Recommended diameter for attachment bolts, mm G10 mm
Recommended diameter for attachment bolts, inch G0.375 in
Housing
Bearing
End cover
