FYTB 3/4 TF SKF  expansion type: Non-Expansion Bearing (Fixed) Bearing units

FYTB 3/4 TF SKF expansion type: Non-Expansion Bearing (Fixed) Bearing units

Bearing numberFYTB 3/4 TFBrandSKFBore Diameter (mm)19.05Width (mm)31d19.05 mms118.3 mmA129.5 mmB31 mmG10 mmH112 mmJ90 mmL60.5 mmN11.5 mmT37.3 mmA211 mmWeight0.5 KgBasic dynamic load rating (C)12.7 kNBasic static load rating (C0)6.55 kNFatigue load limit (Pu)0.28CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/A…
Contact Us Now !

Product description

FYTB 3/4 TF SKF expansion type: Non-Expansion Bearing (Fixed) Bearing units

Bearing numberFYTB 3/4 TF
BrandSKF
Bore Diameter (mm)19.05
Width (mm)31
d19.05 mm
s118.3 mm
A129.5 mm
B31 mm
G10 mm
H112 mm
J90 mm
L60.5 mm
N11.5 mm
T37.3 mm
A211 mm
Weight0.5 Kg
Basic dynamic load rating (C)12.7 kN
Basic static load rating (C0)6.55 kN
Fatigue load limit (Pu)0.28
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.5
EAN7316570338812
Product Group – BDIB04144
Number of Mounting Holes2
Mounting MethodSet Screw
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts3/8 Inch
RelubricatableYes
Insert Part NumberYAR 204-012-2F
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description2 Bolt Flange Block; 3/4" Bore; 3-1/2" Bolt Circle; 3.543" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 1.221" Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYTB 3/4 TF
Weight / LBS1.1
Nominal Bolt Circle Diameter Round3.5 Inch | 90 Millimeter
Bolt Spacing3.543 Inch | 90 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Length Thru Bore1.221 Inch | 31.013 Millimeter
Bore0.75 Inch | 19.05 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
bore diameter:0.7500 in
radial dynamic load capacity:2855 lbf
bolt center-to-center length:3.5433 in
radial static load capacity:1472 lbf
overall length/diameter:4.4095 in
length through bore:1.2205 in
overall height:1.4685 in
finish/coating:Blue Alkyd/Acryl Paint (RAL 5007)
bore type:Round
bolt size:0.4528 in
mounting type:Two-Bolt Flange
maximum rpm:8500 rpm
housing material:Cast Iron
lubrication type:Lubrication Fitting
locking device:Set Screw
series:FYTB
expansion type:Non-Expansion Bearing (Fixed)
manufacturer product page:Click here
bearing material:Steel
manufacturer upc number:7316570338812
Rα45 °
DN6.5 mm
SWN7 mm
Housing materialCast iron
Da50.8 mm
Db158 mm
Db260.5 mm
A29.5 mm
A111 mm
A33.2 mm
A518.5 mm
B44.5 mm
s118.3 mm
RG1/4-28 UNF
R120 mm
GN1/4-28 SAE-LT
J674 mm
J711.5 mm
N42 mm
Basic dynamic load rating C12.7 kN
Basic static load rating C06.55 kN
Fatigue load limit Pu0.28 kN
Limiting speed8500 r/min
Mass bearing unit0.46 kg
Thread grub screw G21/4-28 UNF
Hexagonal key size for grub screw N3.175 mm
Recommended tightening torque for grub screw4 N·m
Recommended diameter for attachment bolts, mm G10 mm
Recommended diameter for attachment bolts, inch G0.375 in
Housing
Bearing
End cover
