FYTB 50 WF SKF  Number of Mounting Holes 2 Bearing units

FYTB 50 WF SKF Number of Mounting Holes 2 Bearing units

Bearing numberFYTB 50 WFBrandSKFBore Diameter (mm)50d50 mmDa101.6 mms138.1 mmA143 mmB162.7 mmG16 mmH189 mmJ157 mmL116 mmN18 mmT66.1 mmA215 mmWeight2.35 KgBasic dynamic load rating (C)35.1 kNBasic static load rating (C0)23.2 kNFatigue load limit (Pu)0.98CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / …
Contact Us Now !

Product description

FYTB 50 WF SKF Number of Mounting Holes 2 Bearing units

Bearing numberFYTB 50 WF
BrandSKF
Bore Diameter (mm)50
d50 mm
Da101.6 mm
s138.1 mm
A143 mm
B162.7 mm
G16 mm
H189 mm
J157 mm
L116 mm
N18 mm
T66.1 mm
A215 mm
Weight2.35 Kg
Basic dynamic load rating (C)35.1 kN
Basic static load rating (C0)23.2 kN
Fatigue load limit (Pu)0.98
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram2.35
EAN7316570945997
Product Group – BDIM06110
Number of Mounting Holes2
Mounting MethodEccentric Collar
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts16 Millimeter
RelubricatableYes
Insert Part NumberYEL 210-2F
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricMetric
Long Description2 Bolt Flange Block; 50MM Bore; 157MM Bolt Circle; 157MM Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Iron; Ball Bearing; 62.7MM Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYTB 50 WF
Weight / LBS5.18
Bolt Spacing6.181 Inch | 157 Millimeter
Nominal Bolt Circle Diameter Round6.2 Inch | 157 Millimeter
Length Thru Bore2.469 Inch | 62.7 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Bore1.969 Inch | 50 Millimeter
Housing materialCast iron
Da101.6 mm
Db1107 mm
Db2116 mm
A43 mm
A115 mm
A33.2 mm
A529.5 mm
B162.7 mm
B46.75 mm
s138.1 mm
RG1/4-28 UNF
R128.5 mm
Rα45 °
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J6127 mm
J720 mm
N42 mm
Basic dynamic load rating C35.1 kN
Basic static load rating C023.2 kN
Fatigue load limit Pu0.98 kN
Limiting speed4000 r/min
Mass bearing unit2.2 kg
Thread grub screw G2M10x1
Hexagonal key size for grub screw N5 mm
Recommended tightening torque for grub screw16.5 N·m
Recommended diameter for attachment bolts, mm G16 mm
Recommended diameter for attachment bolts, inch G0.625 in
Housing
Bearing
End cover
