FYWR 1.1/4 AYTHR SKF Hexagonal key size for grub screw – H 3.175 mm 31.75×34.1×13.5mm  Bearing units

FYWR 1.1/4 AYTHR SKF Hexagonal key size for grub screw – H 3.175 mm 31.75×34.1×13.5mm Bearing units

Bearing numberFYWR 1.1/4 AYTHRSize (mm)31.75x34.1x13.5BrandSKFBore Diameter (mm)31.75Outer Diameter (mm)34.1Width (mm)13.5d31.75 mmA34.1 mmA113.5 mmA529.3 mmB38.1 mmDb174.1 mmDb278.4 mmJ82.6 mmL108 mmH12.7 mms122.2 mmT42 mmRG - 1/4-28 UNF1/428 UNFR122.7 mmBasic dynamic load rating - C16.3 kNBasic static load rating - C011.2 kNFatigue load limit - P…
Contact Us Now !

Product description

FYWR 1.1/4 AYTHR SKF Hexagonal key size for grub screw – H 3.175 mm 31.75×34.1×13.5mm Bearing units

Bearing numberFYWR 1.1/4 AYTHR
Size (mm)31.75×34.1×13.5
BrandSKF
Bore Diameter (mm)31.75
Outer Diameter (mm)34.1
Width (mm)13.5
d31.75 mm
A34.1 mm
A113.5 mm
A529.3 mm
B38.1 mm
Db174.1 mm
Db278.4 mm
J82.6 mm
L108 mm
H12.7 mm
s122.2 mm
T42 mm
RG – 1/4-28 UNF1/428 UNF
R122.7 mm
Basic dynamic load rating – C16.3 kN
Basic static load rating – C011.2 kN
Fatigue load limit – Pu0.475 kN
Limiting speed3800 r/min
Mass bearing unit1.35 kg
Thread – G2 – 1/4-28 UNF1/428 UNF
Hexagonal key size for grub screw – H3.175 mm
Housing materialStainless steel
Db174.1 mm
Db278.4 mm
A113.5 mm
A529.3 mm
N12.7 mm
s122.2 mm
RG1/4-28 UNF
R122.7 mm
Basic dynamic load rating C16.3 kN
Basic static load rating C011.2 kN
Fatigue load limit Pu0.475 kN
Thread grub screw G21/4-28 UNF
Hexagonal key size for grub screw N3.175 mm
Recommended tightening torque for grub screw4 N·m
Recommended diameter for attachment bolts, mm G10 mm
Recommended diameter for attachment bolts, inch G0.4375 in
Housing
FYWR 506 Y
Bearing
End cover
