Home > Thrust roller bearings > K 81112 TN SKF Precision Class ABEC 1 | ISO P0 85x60x7.5mm Thrust roller bearings
K 81112 TN SKF Precision Class ABEC 1 | ISO P0 85x60x7.5mm  Thrust roller bearings

K 81112 TN SKF Precision Class ABEC 1 | ISO P0 85x60x7.5mm Thrust roller bearings

Bearing numberK 81112 TNSize (mm)85x60x7.5BrandSKFBore Diameter (mm)85Outer Diameter (mm)60Width (mm)7.5d60 mmD85 mmDw7.5 mmEa62 mmEb82 mmBasic dynamic load rating - C80 kNBasic static load rating - C0300 kNFatigue load limit - Pu30.5 kNReference speed1800 r/minLimiting speed3600 r/minCategoryThrust Roller BearingBDI Inventory0.0Manufacturer NameSK…
Contact Us Now !

Product description

K 81112 TN SKF Precision Class ABEC 1 | ISO P0 85x60x7.5mm Thrust roller bearings

Bearing numberK 81112 TN
Size (mm)85x60x7.5
BrandSKF
Bore Diameter (mm)85
Outer Diameter (mm)60
Width (mm)7.5
d60 mm
D85 mm
Dw7.5 mm
Ea62 mm
Eb82 mm
Basic dynamic load rating – C80 kN
Basic static load rating – C0300 kN
Fatigue load limit – Pu30.5 kN
Reference speed1800 r/min
Limiting speed3600 r/min
CategoryThrust Roller Bearing
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.11
EAN7316577122896
Product Group – BDIB04144
Rolling ElementCylindrical Roller Bearing
Self AligningNo
Component DescriptionRoller Assembly Only
Thrust BearingYes
Single or Double DirectionSingle Direction
BandedNo
Cage MaterialPolyamide
Precision ClassABEC 1 | ISO P0
Other FeaturesSingle Row | Injection Molded Cage
Long Description60MM Bore 1; 60MM Bore 2; 85MM Outside Diameter; 7.5MM Height; Cylindrical Roller Bearing; Single Direction; Not Self Aligning; Not Banded; Polyamide Cage; ABEC 1 | ISO P0; Roller Assembly Only
Inch – MetricMetric
Category – BDIThrust Roller Bearings
UNSPSC31171500
Harmonized Tariff Code8482.99.25.60
NounRoller Assembly
Keyword StringThrust Cylindrical
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberK 81112 TN
Weight / LBS0.236
Height0.295 Inch | 7.5 Millimeter
Bore 12.362 Inch | 60 Millimeter
Outside Diameter3.346 Inch | 85 Millimeter
Overall Height with Aligning Washer0 Inch | 0 Millimeter
Bore 22.362 Inch | 60 Millimeter
Dw7.5 mm
Ea62 mm
Eb82 mm
Basic dynamic load rating C80 kN
Basic static load rating C0300 kN
Fatigue load limit Pu30.5 kN
Mass roller and cage thrust assembly0.082 kg
Roller and cage thrust assemblyK 81112 TN
Shaft washer
Housing washer
Universal washer
