K81128-TV INA 140x180x12mm  Single or Double Direction Single Direction Thrust roller bearings

K81128-TV INA 140x180x12mm Single or Double Direction Single Direction Thrust roller bearings

Bearing numberK81128-TVSize (mm)140x180x12BrandINABore Diameter (mm)140Outer Diameter (mm)180Width (mm)12Dc1140 mmDc180 mmDw12 mmEa175 mmEb145 mmm0.4 kg / WeightCa260000 N / Dynamic load rating (axial)C0a960000 N / Static load rating (axial)Cua83000 N / Fatigue limit loadnG1820 1/min / Limiting speednB710 1/min / Reference speedGS81128 / Allocated …
Contact Us Now !

Product description

K81128-TV INA 140x180x12mm Single or Double Direction Single Direction Thrust roller bearings

Bearing numberK81128-TV
Size (mm)140x180x12
BrandINA
Bore Diameter (mm)140
Outer Diameter (mm)180
Width (mm)12
Dc1140 mm
Dc180 mm
Dw12 mm
Ea175 mm
Eb145 mm
m0.4 kg / Weight
Ca260000 N / Dynamic load rating (axial)
C0a960000 N / Static load rating (axial)
Cua83000 N / Fatigue limit load
nG1820 1/min / Limiting speed
nB710 1/min / Reference speed
GS81128 / Allocated housing locating washer
WS81128 / Allocated shaft locating washer
CategoryThrust Roller Bearing
BDI Inventory0.0
Manufacturer NameSCHAEFFLER GROUP
Minimum Buy QuantityN/A
Weight / Kilogram0.476
Product Group – BDIB04144
Rolling ElementCylindrical Roller Bearing
Self AligningNo
Component DescriptionRoller Assembly Only
Thrust BearingYes
Single or Double DirectionSingle Direction
BandedNo
Cage MaterialPolyamide
Precision ClassABEC 1 | ISO P0
Other FeaturesSingle Row | ISO Series 1 and 4
Long Description140MM Bore 1; 140MM Bore 2; 180MM Outside Diameter; 12MM Height; Cylindrical Roller Bearing; Single Direction; Not Self Aligning; Not Banded; Polyamide Cage; ABEC 1 | ISO P0; Roller Assembly Only
Inch – MetricMetric
Category – BDIThrust Roller Bearings
UNSPSC31171500
Harmonized Tariff Code8482.99.25.60
NounRoller Assembly
Keyword StringThrust Cylindrical
Manufacturer URLhttp://www.ina.com
Manufacturer Item NumberK81128TN
Weight / LBS0.882
Outside Diameter7.087 Inch | 180 Millimeter
Bore 15.512 Inch | 140 Millimeter
Bore 25.512 Inch | 140 Millimeter
Overall Height with Aligning Washer0 Inch | 0 Millimeter
Height0.472 Inch | 12 Millimeter
