NJ 2306 ECPH SKF F 40.5 mm 72x30x27mm  Thrust ball bearings

NJ 2306 ECPH SKF F 40.5 mm 72x30x27mm Thrust ball bearings

Bearing numberNJ 2306 ECPHSize (mm)72x30x27BrandSKFBore Diameter (mm)72Outer Diameter (mm)30Width (mm)27d30 mmD72 mmB27 mmd145 mmD158.35 mmF40.5 mmr1,2 - min.1.1 mmr3,4 - min.1.1 mms2.4 mmda - min.37 mmda - max.39 mmdb - min.47 mmDa - max.65.1 mmra - max.1 mmBasic dynamic load rating - C83 kNBasic static load rating - C075 kNFatigue load limit - Pu…
Contact Us Now !

Product description

NJ 2306 ECPH SKF F 40.5 mm 72x30x27mm Thrust ball bearings

Bearing numberNJ 2306 ECPH
Size (mm)72x30x27
BrandSKF
Bore Diameter (mm)72
Outer Diameter (mm)30
Width (mm)27
d30 mm
D72 mm
B27 mm
d145 mm
D158.35 mm
F40.5 mm
r1,2 – min.1.1 mm
r3,4 – min.1.1 mm
s2.4 mm
da – min.37 mm
da – max.39 mm
db – min.47 mm
Da – max.65.1 mm
ra – max.1 mm
Basic dynamic load rating – C83 kN
Basic static load rating – C075 kN
Fatigue load limit – Pu9.6 kN
Reference speed11000 r/min
Limiting speed12000 r/min
Calculation factor – kr0.25
d145 mm
D158.35 mm
r1,2 min.1.1 mm
r3,4 min.1.1 mm
s max.2.4 mm
da min.37 mm
da max.39 mm
db min.47 mm
Da max.65.1 mm
ra max.1 mm
Basic dynamic load rating C83 kN
Basic static load rating C075 kN
Fatigue load limit Pu9.65 kN
Calculation factor kr0.25
Limiting value e0.3
Axial load factor Y0.4
Mass bearing0.54 kg

Cross-reference to other manufacturer’s part number

XLJ8.1/2 Deep groove ball bearings

Basic dynamic load rating (C):108 kN , Weight:7.44 Kg , (Grease) Lubrication Speed:900 r/min , Basic static load rating (C0):123 kN , B:38.1 mm , C:38.1 mm
AST20 25050 Plain bearings

Lube Hole Dia. (dl):9.500 , Material:Carbon steel shell with POM plastic liner , ID Chamfer Angle (B deg.):45 , OD Chamfer Length (Co):1.800 , Bearing Length Tolerance (B tol.) – +0 / -0.40:+0 / 0.40 , ID Chamfer Length (Ci):0.800
AST20 20050 Plain bearings

Lube Hole Dia. (dl):9.500 , Material:Carbon steel shell with POM plastic liner , ID Chamfer Length (Ci):0.800 , ID Chamfer Angle (B deg.):45
BA 1422 Z Needle roller bearings

Basic dynamic load rating (C):24.1 kN , D:28.575 mm , Weight:0.0425 Kg , Basic static load rating (C0):45.7 kN , C:34.92 mm
KTSOS30-PP-AS Linear bearings

H:60 mm , Weight:1.8 Kg , Basic dynamic load rating (C):9.6 kN , D:47 mm , H2:35 mm , C2:106 mm
X30216/YHA30216 Tapered roller bearings

Basic dynamic load rating (C90):39.3 , Calculation factor (e):0.42 , Basic dynamic load rating (Ca90):28.2 , Factor (K):1.39 , Basic dynamic load rating (C1):151 kN
29380-M Thrust roller bearings

Basic dynamic load rating (C):3290 kN , Weight:150 Kg , D1:494 mm , Basic static load rating (C0):14120 kN
FY 35 TF/VA228 Bearing units

Hexagonal key size for grub screw N:3 mm , Bearing:
YAR 207-2FW/VA228
, Attachment bolts, recommended metric size G:12 mm , Limiting temperature T max.:350 °C , Basic static load rating C0:15.3 kN , Grub (set) screw G2:M6x0.75
ER3.25.2800.400-1SPPN Thrust roller bearings

Fi:2685 mm , He:117 mm , Fe:2925 mm , Ht:147 mm , Hi:138 mm
3201 Angular contact ball bearings

Basic static load rating (C0):7.15 kN , C:15.9 mm , Basic dynamic load rating (C):9.7 kN , Weight:0.063 Kg , (Grease) Lubrication Speed:14000 r/min , r min.:0.6 mm
