NU 1016 ECM SKF Reference speed 6000 r/min 125x80x22mm  Thrust ball bearings

NU 1016 ECM SKF Reference speed 6000 r/min 125x80x22mm Thrust ball bearings

Bearing numberNU 1016 ECMSize (mm)125x80x22BrandSKFBore Diameter (mm)125Outer Diameter (mm)80Width (mm)22d80 mmD125 mmB22 mmD1111 mmF91.5 mmr1,2 - min.1.1 mmr3,4 - min.1 mms1.5 mmda - min.86 mmda - max.90 mmdb - min.99 mmDa - max.119 mmra - max.1 mmrb - max.1 mmBasic dynamic load rating - C99 kNBasic static load rating - C0127 kNFatigue load limit …
Contact Us Now !

Product description

NU 1016 ECM SKF Reference speed 6000 r/min 125x80x22mm Thrust ball bearings

Bearing numberNU 1016 ECM
Size (mm)125x80x22
BrandSKF
Bore Diameter (mm)125
Outer Diameter (mm)80
Width (mm)22
d80 mm
D125 mm
B22 mm
D1111 mm
F91.5 mm
r1,2 – min.1.1 mm
r3,4 – min.1 mm
s1.5 mm
da – min.86 mm
da – max.90 mm
db – min.99 mm
Da – max.119 mm
ra – max.1 mm
rb – max.1 mm
Basic dynamic load rating – C99 kN
Basic static load rating – C0127 kN
Fatigue load limit – Pu16.3 kN
Reference speed6000 r/min
Limiting speed6000 r/min
Calculation factor – kr0.1
D1111 mm
r1,2 min.1.1 mm
r3,4 min.1 mm
s max.1.5 mm
da min.86 mm
da max.90 mm
db min.99 mm
Da max.119 mm
ra max.1 mm
rb max.1 mm
Basic dynamic load rating C99 kN
Basic static load rating C0127 kN
Fatigue load limit Pu16.3 kN
Calculation factor kr0.1
Limiting value e0.2
Axial load factor Y0.6
Mass bearing1.04 kg
