NU 217 ECJ SKF 150x85x28mm  Bore Diameter  150mm Thrust ball bearings

NU 217 ECJ SKF 150x85x28mm Bore Diameter 150mm Thrust ball bearings

CategoryCylindrical Roller BearingsBDI Inventory2.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogram1.9EAN7316577043306Product Group - BDIB04144Bore ProfileStraightCage MaterialSteelPrecision ClassRBEC 1 | ISO P0Number of Rows of RollersSingle RowSeparableInner Ring - Both SidesRolling ElementCylindrical Roller BearingProfileComplete wit…
Contact Us Now !

Product description

NU 217 ECJ SKF 150x85x28mm Bore Diameter 150mm Thrust ball bearings

CategoryCylindrical Roller Bearings
BDI Inventory2.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram1.9
EAN7316577043306
Product Group – BDIB04144
Bore ProfileStraight
Cage MaterialSteel
Precision ClassRBEC 1 | ISO P0
Number of Rows of RollersSingle Row
SeparableInner Ring – Both Sides
Rolling ElementCylindrical Roller Bearing
ProfileComplete with Outer and Inner Ring
Snap RingNo
Internal ClearanceC0-Medium
RetainerYes
RelubricatableYes
Inch – MetricMetric
Other FeaturesHigh Capacity | Plain Inner Ring | 2 Rib Outer Ring | Cage on Outer Ring ID
Long Description85MM Bore; Straight Bore Profile; 150MM Outside Diameter; 28MM Width; Steel Cage Matetrial; RBEC 1 | ISO P0; Single Row; Inner Ring – Both Sides Separable; No Snap Ring; Relubricatable; C0-Medium Internal Clearance; Retainer
Category – BDICylindrical Roller Bearing
UNSPSC31171547
Harmonized Tariff Code8482.50.00.00
NounBearing
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberNU 217 ECJ
Weight / LBS4.187
Outside Diameter5.906 Inch | 150 Millimeter
Width1.102 Inch | 28 Millimeter
Bore3.346 Inch | 85 Millimeter
Bearing numberNU 217 ECJ
Size (mm)150x85x28
BrandSKF
Bore Diameter (mm)150
Outer Diameter (mm)85
Width (mm)28
d85 mm
D150 mm
B28 mm
D1130.3 mm
F100.5 mm
r1,2 – min.2 mm
r3,4 – min.2 mm
s1.5 mm
da – min.96 mm
da – max.98 mm
db – min.103 mm
Da – max.138.5 mm
ra – max.2 mm
rb – max.2 mm
Basic dynamic load rating – C190 kN
Basic static load rating – C0200 kN
Fatigue load limit – Pu25 kN
Reference speed4800 r/min
Limiting speed5300 r/min
Calculation factor – kr0.15
bore diameter:85 mm
static load capacity:200 kN
outside diameter:150 mm
maximum rpm:5300 rpm
overall width:28 mm
bearing material:Steel
flanges:(2) Flanges on outer Ring. Flangeless Inner Ring
cage material:Pressed Steel
bore type:Straight
finish/coating:Uncoated
number of rows:1
closure type:Open
operating temperature range:Maximum 302 °F
series:NU
dynamic load capacity:190 kN
manufacturer upc number:7316577043306
D1130.3 mm
r1,2 min.2 mm
r3,4 min.2 mm
s max.1.5 mm
da min.96 mm
da max.98 mm
db min.103 mm
Da max.138.5 mm
ra max.2 mm
rb max.2 mm
Basic dynamic load rating C190 kN
Basic static load rating C0200 kN
Fatigue load limit Pu25 kN
Calculation factor kr0.15
Limiting value e0.2
Axial load factor Y0.6
Mass bearing1.85 kg
Angle ring
