NU 2209 ECJ SKF 85x45x23mm  Mass bearing 0.54 kg Thrust ball bearings

NU 2209 ECJ SKF 85x45x23mm Mass bearing 0.54 kg Thrust ball bearings

CategoryCylindrical Roller BearingsBDI Inventory1.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogram0.56Product Group - BDIB04144Bore ProfileStraightCage MaterialSteelPrecision ClassRBEC 1 | ISO P0Number of Rows of RollersSingle RowSeparableInner Ring - Both SidesRolling ElementCylindrical Roller BearingProfileComplete with Outer and Inn…
Contact Us Now !

Product description

NU 2209 ECJ SKF 85x45x23mm Mass bearing 0.54 kg Thrust ball bearings

CategoryCylindrical Roller Bearings
BDI Inventory1.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.56
Product Group – BDIB04144
Bore ProfileStraight
Cage MaterialSteel
Precision ClassRBEC 1 | ISO P0
Number of Rows of RollersSingle Row
SeparableInner Ring – Both Sides
Rolling ElementCylindrical Roller Bearing
ProfileComplete with Outer and Inner Ring
Snap RingNo
Internal ClearanceC0-Medium
RetainerYes
RelubricatableYes
Inch – MetricMetric
Other FeaturesHigh Capacity | Plain Inner Ring | 2 Rib Outer Ring | Cage on Outer Ring ID
Long Description45MM Bore; Straight Bore Profile; 85MM Outside Diameter; 23MM Width; Steel Cage Matetrial; RBEC 1 | ISO P0; Single Row; Inner Ring – Both Sides Separable; No Snap Ring; Relubricatable; C0-Medium Internal Clearance; Retainer
Category – BDICylindrical Roller Bearing
UNSPSC31171547
Harmonized Tariff Code8482.50.00.00
NounBearing
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberNU 2209 ECJ
Weight / LBS1.235
Bore1.772 Inch | 45 Millimeter
Width0.906 Inch | 23 Millimeter
Outside Diameter3.346 Inch | 85 Millimeter
Bearing numberNU 2209 ECJ
Size (mm)85x45x23
BrandSKF
Bore Diameter (mm)85
Outer Diameter (mm)45
Width (mm)23
d45 mm
D85 mm
B23 mm
D172.4 mm
F54.5 mm
r1,2 – min.1.1 mm
r3,4 – min.1.1 mm
s1.7 mm
da – min.52 mm
da – max.53 mm
db – min.56 mm
Da – max.77.6 mm
ra – max.1 mm
rb – max.1 mm
Basic dynamic load rating – C85 kN
Basic static load rating – C081.5 kN
Fatigue load limit – Pu10.6 kN
Reference speed9000 r/min
Limiting speed9500 r/min
Calculation factor – kr0.2
D172.4 mm
r1,2 min.1.1 mm
r3,4 min.1.1 mm
s max.1.7 mm
da min.52 mm
da max.53 mm
db min.56 mm
Da max.77.6 mm
ra max.1 mm
rb max.1 mm
Basic dynamic load rating C85 kN
Basic static load rating C081.5 kN
Fatigue load limit Pu10.6 kN
Calculation factor kr0.2
Limiting value e0.3
Axial load factor Y0.4
Mass bearing0.54 kg

Cross-reference to other manufacturer’s part number

UKSP207H Bearing units

L1:225 mm , Weight:2.1 Kg , Basic dynamic load rating (C):25.7 kN , L:274 mm , Thread (G):R1/8"
24164-K30-MB-W33 Spherical roller bearings

Calculation factor (Y1):1.68 , Calculation factor (e):0.4 , Limiting speed:900 r/min , Basic dynamic load rating (C):3739 kN , Basic static load rating (C0):7102 kN , Calculation factor (Y0):1.64
21317AX Cylindrical roller bearings

Calculation factor (e):0.26 , Calculation factor (Y0):2.49 , Calculation factor (Y1):2.55 , (Oil) Lubrication Speed:5100 r/min
ARX15X58X77 Needle roller bearings

d:15.000 mm , Outer Diameter :58.000mm , D:58.000 mm , Width :77.000mm , T:77.000 mm
1302G14 Self aligning ball bearings

B:13.000 mm , d:15.000 mm , C:13.000 mm , D:42.000 mm , Width :13.000mm
AST11 9060 Plain bearings

Material:Bronze shell with PTFE / Fiber lining , Bearing Length Tolerance (B tol.) – +0 / -0.40:+0 / 0.40 , OD Chamfer Length (Co):1.800 , ID Chamfer Angle (B deg.):45 , ID Chamfer Length (Ci):0.600
11212TN9 Self aligning ball bearings

Calculation factor (kr):0.04 , Calculation factor (e):0.19 , Limiting speed:3400 r/min , Fatigue load limit (Pu):0.62 , Calculation factor (Y0):3.6 , Calculation factor (Y1):3.3
110055/110098X Tapered roller bearings

Da:92 mm , da:70 mm , Weight:0.885 Kg , r:2.5 mm , R:2 mm , F:5.5 mm
QT9 Tapered roller bearings

r min.:2.5 mm , Basic static load rating (C0):200 kN , Weight:3 Kg , Basic dynamic load rating (C):165 kN , r1 min.:3 mm
NAXI 1425 Complex bearings

Product Group – BDI:B04144 , Weight / Kilogram:0 , Manufacturer Name:IKO , Minimum Buy Quantity:N/A , BDI Inventory:0.0
