NU 2312 ECP SKF Outside Diameter 5.118 Inch | 130 Millimeter 130x60x46mm  Thrust ball bearings

NU 2312 ECP SKF Outside Diameter 5.118 Inch | 130 Millimeter 130x60x46mm Thrust ball bearings

Bearing numberNU 2312 ECPSize (mm)130x60x46BrandSKFBore Diameter (mm)130Outer Diameter (mm)60Width (mm)46d60 mmD130 mmB46 mmD1108.5 mmF77 mmr1,2 - min.2.1 mmr3,4 - min.2.1 mms3.6 mmda - min.72 mmda - max.74 mmdb - min.79 mmDa - max.118.1 mmra - max.2 mmrb - max.2 mmBasic dynamic load rating - C260 kNBasic static load rating - C0265 kNFatigue load l…
Contact Us Now !

Product description

NU 2312 ECP SKF Outside Diameter 5.118 Inch | 130 Millimeter 130x60x46mm Thrust ball bearings

Bearing numberNU 2312 ECP
Size (mm)130x60x46
BrandSKF
Bore Diameter (mm)130
Outer Diameter (mm)60
Width (mm)46
d60 mm
D130 mm
B46 mm
D1108.5 mm
F77 mm
r1,2 – min.2.1 mm
r3,4 – min.2.1 mm
s3.6 mm
da – min.72 mm
da – max.74 mm
db – min.79 mm
Da – max.118.1 mm
ra – max.2 mm
rb – max.2 mm
Basic dynamic load rating – C260 kN
Basic static load rating – C0265 kN
Fatigue load limit – Pu34.5 kN
Reference speed5600 r/min
Limiting speed6700 r/min
Calculation factor – kr0.25
CategoryCylindrical Roller Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram2.801
EAN7316577028389
Product Group – BDIB04144
Bore ProfileStraight
Cage MaterialPolymer
Precision ClassRBEC 1 | ISO P0
Number of Rows of RollersSingle Row
SeparableInner Ring – Both Sides
Rolling ElementCylindrical Roller Bearing
ProfileComplete with Outer and Inner Ring
Snap RingNo
Internal ClearanceC0-Medium
RetainerYes
RelubricatableYes
Inch – MetricMetric
Other FeaturesHigh Capacity | Plain Inner Ring | 2 Rib Outer Ring | Cage on Outer Ring ID
Long Description60MM Bore; Straight Bore Profile; 130MM Outside Diameter; 46MM Width; Polymer Cage Matetrial; RBEC 1 | ISO P0; Single Row; Inner Ring – Both Sides Separable; No Snap Ring; Relubricatable; C0-Medium Internal Clearance; Retainer
Category – BDICylindrical Roller Bearing
UNSPSC31171547
Harmonized Tariff Code8482.50.00.00
NounBearing
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberNU 2312 ECP
Weight / LBS6.169
Bore2.362 Inch | 60 Millimeter
Width1.811 Inch | 46 Millimeter
Outside Diameter5.118 Inch | 130 Millimeter
bore diameter:60 mm
precision rating:RBEC 1 (ISO Class Normal)
outside diameter:130 mm
maximum rpm:6700 RPM
overall width:46 mm
bearing material:Steel
flanges:(2) Outer Ring
cage material:Polyamide
bore type:Straight
finish/coating:Uncoated
number of rows:1
closure type:Open
internal clearance:C0
application:Piston Type Machines. Rolling Mills. Spindles/Machine Tools
ring separation:Separable Ring
outer ring width:46 mm
operating temperature range:Maximum of +300 °F
fillet radius:2 mm
dynamic load capacity:260 kN
series:NU23
static load capacity:265 kN
D1108.5 mm
r1,2 min.2.1 mm
r3,4 min.2.1 mm
s max.3.6 mm
da min.72 mm
da max.74 mm
db min.79 mm
Da max.118.1 mm
ra max.2 mm
rb max.2 mm
Basic dynamic load rating C260 kN
Basic static load rating C0265 kN
Fatigue load limit Pu34.5 kN
Calculation factor kr0.25
Limiting value e0.3
Axial load factor Y0.4
Mass bearing2.74 kg
Angle ring

Cross-reference to other manufacturer’s part number

130RU30 Cylindrical roller bearings

B:52 mm , D:200 mm , C:52 mm , E:187 mm , r max:2 mm
LH-22212BK Spherical roller bearings

Basic static load rating (C0):147 kN , Calculation factor (e):0.27 , (Grease) Lubrication Speed:4 100 r/min , (Oil) Lubrication Speed:5 300 r/min , Calculation factor (Y0):2.44 , Calculation factor (Y1):2.49
YTM405421JAM Needle roller bearings

Bore Diameter :40mm , d:40 mm , Outer Diameter :54mm , Width :21mm , D:54 mm
NAXI 1730 Complex bearings

Manufacturer Name:IKO , Weight / Kilogram:0 , BDI Inventory:0.0 , Product Group – BDI:B04144 , Minimum Buy Quantity:N/A
TAM 820 Needle roller bearings

BDI Inventory:0.0 , Weight / Kilogram:0 , Minimum Buy Quantity:N/A , Product Group – BDI:B04144 , Manufacturer Name:IKO
RSU 14 0644 Thrust ball bearings

Di:645 mm , da:643 mm , La:690 mm , na:36 mm , ni:36 mm , Li:598 mm
LBB 16 UU OP Linear bearings

Material:52100 chrome steel. or equivalent , Open Gap (a deg.):60.00 , Open Gap (E):0.562 , Weight (g):128.00
11212G15 Self aligning ball bearings

B:62 mm , C:22 mm , d:60.000 mm , Width :62mm , D:110.000 mm
1216-K+H216 Self aligning ball bearings

D1:105 mm , Basic static load rating (C0):16.1 kN , Weight:2.5 Kg , Basic dynamic load rating (C):30.5 kN
AXK 6590 Needle roller bearings

Basic static load rating (C0):254.6 kN , Basic dynamic load rating (C):45.8 kN , H:3 mm , Weight:0.035 Kg
