Home > Thrust ball bearings > NU 315 ECP SKF 160x75x37mm finish/coating: Uncoated Thrust ball bearings
NU 315 ECP SKF 160x75x37mm finish/coating: Uncoated Thrust ball bearings
Bearing numberNU 315 ECPSize (mm)160x75x37BrandSKFBore Diameter (mm)160Outer Diameter (mm)75Width (mm)37d75 mmD160 mmB37 mmD1135 mmF95 mmr1,2 - min.2.1 mmr3,4 - min.2.1 mms1.8 mmda - min.87 mmda - max.92 mmdb - min.97 mmDa - max.148 mmra - max.2 mmrb - max.2 mmBasic dynamic load rating - C280 kNBasic static load rating - C0265 kNFatigue load limit …
Product description
NU 315 ECP SKF 160x75x37mm finish/coating: Uncoated Thrust ball bearings
| Bearing number | NU 315 ECP |
| Size (mm) | 160x75x37 |
| Brand | SKF |
| Bore Diameter (mm) | 160 |
| Outer Diameter (mm) | 75 |
| Width (mm) | 37 |
| d | 75 mm |
| D | 160 mm |
| B | 37 mm |
| D1 | 135 mm |
| F | 95 mm |
| r1,2 – min. | 2.1 mm |
| r3,4 – min. | 2.1 mm |
| s | 1.8 mm |
| da – min. | 87 mm |
| da – max. | 92 mm |
| db – min. | 97 mm |
| Da – max. | 148 mm |
| ra – max. | 2 mm |
| rb – max. | 2 mm |
| Basic dynamic load rating – C | 280 kN |
| Basic static load rating – C0 | 265 kN |
| Fatigue load limit – Pu | 33.5 kN |
| Reference speed | 4500 r/min |
| Limiting speed | 5300 r/min |
| Calculation factor – kr | 0.15 |
| Category | Cylindrical Roller Bearings |
| BDI Inventory | 0.0 |
| Manufacturer Name | SKF |
| Minimum Buy Quantity | N/A |
| Weight / Kilogram | 3.37 |
| EAN | 7316577030313 |
| Product Group – BDI | B04144 |
| Bore Profile | Straight |
| Cage Material | Polymer |
| Precision Class | RBEC 1 | ISO P0 |
| Number of Rows of Rollers | Single Row |
| Separable | Inner Ring – Both Sides |
| Rolling Element | Cylindrical Roller Bearing |
| Profile | Complete with Outer and Inner Ring |
| Snap Ring | No |
| Internal Clearance | C0-Medium |
| Retainer | Yes |
| Relubricatable | Yes |
| Inch – Metric | Metric |
| Other Features | High Capacity | Plain Inner Ring | 2 Rib Outer Ring | Cage on Outer Ring ID |
| Long Description | 75MM Bore; Straight Bore Profile; 160MM Outside Diameter; 37MM Width; Polymer Cage Matetrial; RBEC 1 | ISO P0; Single Row; Inner Ring – Both Sides Separable; No Snap Ring; Relubricatable; C0-Medium Internal Clearance; Retainer |
| Category – BDI | Cylindrical Roller Bearing |
| UNSPSC | 31171547 |
| Harmonized Tariff Code | 8482.50.00.00 |
| Noun | Bearing |
| Manufacturer URL | http://www.skf.com |
| Manufacturer Item Number | NU 315 ECP |
| Weight / LBS | 7.423 |
| Bore | 2.953 Inch | 75 Millimeter |
| Width | 1.457 Inch | 37 Millimeter |
| Outside Diameter | 6.299 Inch | 160 Millimeter |
| bore diameter: | 75 mm |
| precision rating: | RBEC 1 (ISO Class Normal) |
| outside diameter: | 160 mm |
| maximum rpm: | 5300 RPM |
| overall width: | 37 mm |
| bearing material: | Steel |
| flanges: | (2) Outer Ring |
| cage material: | Polyamide |
| bore type: | Straight |
| finish/coating: | Uncoated |
| number of rows: | 1 |
| closure type: | Open |
| internal clearance: | C0 |
| application: | Piston Type Machines. Rolling Mills. Spindles/Machine Tools |
| ring separation: | Separable Ring |
| outer ring width: | 37 mm |
| operating temperature range: | Maximum of +300 °F |
| fillet radius: | 2 mm |
| dynamic load capacity: | 280 kN |
| series: | NU3 |
| static load capacity: | 265 kN |
| D1 ≈ | 135 mm |
| r1,2 min. | 2.1 mm |
| r3,4 min. | 2.1 mm |
| s max. | 1.8 mm |
| da min. | 87 mm |
| da max. | 92 mm |
| db min. | 97 mm |
| Da max. | 148 mm |
| ra max. | 2 mm |
| rb max. | 2 mm |
| Basic dynamic load rating C | 280 kN |
| Basic static load rating C0 | 265 kN |
| Fatigue load limit Pu | 33.5 kN |
| Calculation factor kr | 0.15 |
| Limiting value e | 0.2 |
| Axial load factor Y | 0.6 |
| Mass bearing | 3.31 kg |
| Angle ring |
