S71913 CD/HCP4A SKF Static axial stiffness, preload class D 164 N/µm 90x65x13mm  Angular contact ball bearings

S71913 CD/HCP4A SKF Static axial stiffness, preload class D 164 N/µm 90x65x13mm Angular contact ball bearings

Bearing numberS71913 CD/HCP4ASize (mm)90x65x13BrandSKFBore Diameter (mm)90Outer Diameter (mm)65Width (mm)13d65 mmD90 mmB13 mmd172.7 mmd272.7 mmD284.5 mmr1,2 - min.1 mmr3,4 - min.0.3 mma17 mmda - min.69.6 mmda - max.72.1 mmdb - min.69.6 mmdb - max.72.1 mmDa - max.85.4 mmDb - max.88 mmra - max.1 mmrb - max.0.3 mmBasic dynamic load rating - C20.8 kNBa…
Contact Us Now !

Product description

S71913 CD/HCP4A SKF Static axial stiffness, preload class D 164 N/µm 90x65x13mm Angular contact ball bearings

Bearing numberS71913 CD/HCP4A
Size (mm)90x65x13
BrandSKF
Bore Diameter (mm)90
Outer Diameter (mm)65
Width (mm)13
d65 mm
D90 mm
B13 mm
d172.7 mm
d272.7 mm
D284.5 mm
r1,2 – min.1 mm
r3,4 – min.0.3 mm
a17 mm
da – min.69.6 mm
da – max.72.1 mm
db – min.69.6 mm
db – max.72.1 mm
Da – max.85.4 mm
Db – max.88 mm
ra – max.1 mm
rb – max.0.3 mm
Basic dynamic load rating – C20.8 kN
Basic static load rating – C017 kN
Fatigue load limit – Pu0.71 kN
Limiting speed for grease lubrication17000 r/min
Ball – Dw7.938 mm
Ball – z26
Calculation factor – f010.7
Preload class A – GA80 N
Preload class B – GB160 N
Preload class C – GC320 N
Preload class D – GD640 N
Calculation factor – f1.2
Calculation factor – f1
Calculation factor – f2A1
Calculation factor – f2B1.07
Calculation factor – f2C1.12
Calculation factor – f2D1.18
Calculation factor – fHC1.04
Preload class A62 N/micron
Preload class B84 N/micron
Preload class C115 N/micron
Preload class D164 N/micron
d172.7 mm
d272.7 mm
D284.5 mm
r1,2 min.1 mm
r3,4 min.0.3 mm
da min.69.6 mm
da max.72.1 mm
db min.69.6 mm
db max.72.1 mm
Da max.85.4 mm
Db max.88 mm
ra max.1 mm
rb max.0.3 mm
Basic dynamic load rating C20.8 kN
Basic static load rating C017 kN
Fatigue load limit Pu0.71 kN
Attainable speed for grease lubrication17000 r/min
Ball diameter Dw7.938 mm
Number of balls z26
Preload class A GA80 N
Static axial stiffness, preload class A62 N/µm
Preload class B GB160 N
Static axial stiffness, preload class B84 N/µm
Preload class C GC320 N
Static axial stiffness, preload class C115 N/µm
Preload class D GD640 N
Static axial stiffness, preload class D164 N/µm
Calculation factor f1.2
Calculation factor f11
Calculation factor f2A1
Calculation factor f2B1.07
Calculation factor f2C1.12
Calculation factor f2D1.18
Calculation factor fHC1.04
Calculation factor f010.7
Mass bearing0.18 kg
