Home > Angular contact ball bearings > S71916 ACE/P4A SKF 110x80x16mm Static axial stiffness, preload class A 141 N/µm Angular contact ball bearings
S71916 ACE/P4A SKF 110x80x16mm Static axial stiffness, preload class A 141 N/µm Angular contact ball bearings
Bearing numberS71916 ACE/P4ASize (mm)110x80x16BrandSKFBore Diameter (mm)110Outer Diameter (mm)80Width (mm)16d80 mmD110 mmB16 mmd189.3 mmd286.8 mmD2103.6 mmr1,2 - min.1 mmr3,4 - min.0.3 mma32 mmda - min.84.6 mmda - max.88.7 mmdb - min.82 mmdb - max.86.2 mmDa - max.105.4 mmDb - max.108 mmra - max.1 mmrb - max.0.3 mmBasic dynamic load rating - C21.2 k…
Product description
S71916 ACE/P4A SKF 110x80x16mm Static axial stiffness, preload class A 141 N/µm Angular contact ball bearings
| Bearing number | S71916 ACE/P4A |
| Size (mm) | 110x80x16 |
| Brand | SKF |
| Bore Diameter (mm) | 110 |
| Outer Diameter (mm) | 80 |
| Width (mm) | 16 |
| d | 80 mm |
| D | 110 mm |
| B | 16 mm |
| d1 | 89.3 mm |
| d2 | 86.8 mm |
| D2 | 103.6 mm |
| r1,2 – min. | 1 mm |
| r3,4 – min. | 0.3 mm |
| a | 32 mm |
| da – min. | 84.6 mm |
| da – max. | 88.7 mm |
| db – min. | 82 mm |
| db – max. | 86.2 mm |
| Da – max. | 105.4 mm |
| Db – max. | 108 mm |
| ra – max. | 1 mm |
| rb – max. | 0.3 mm |
| Basic dynamic load rating – C | 21.2 kN |
| Basic static load rating – C0 | 17 kN |
| Fatigue load limit – Pu | 0.71 kN |
| Limiting speed for grease lubrication | 14500 r/min |
| Ball – Dw | 9.525 mm |
| Ball – z | 24 |
| Calculation factor – e | 0.68 |
| Calculation factor – Y2 | 0.87 |
| Calculation factor – Y0 | 0.38 |
| Calculation factor – X2 | 0.41 |
| Calculation factor – Y1 | 0.92 |
| Calculation factor – Y2 | 1.41 |
| Calculation factor – Y0 | 0.76 |
| Calculation factor – X2 | 0.67 |
| Preload class A – GA | 195 N |
| Preload class B – GB | 590 N |
| Preload class C – GC | 1170 N |
| Calculation factor – f | 1.19 |
| Calculation factor – f1 | 0.99 |
| Calculation factor – f2A | 1 |
| Calculation factor – f2B | 1.04 |
| Calculation factor – f2C | 1.07 |
| Calculation factor – fHC | 1 |
| Preload class A | 141 N/micron |
| Preload class B | 214 N/micron |
| Preload class C | 281 N/micron |
| d1 | 89.3 mm |
| d2 | 86.8 mm |
| D2 | 103.6 mm |
| r1,2 min. | 1 mm |
| r3,4 min. | 0.3 mm |
| da min. | 84.6 mm |
| da max. | 88.7 mm |
| db min. | 82 mm |
| db max. | 86.2 mm |
| Da max. | 105.4 mm |
| Db max. | 108 mm |
| ra max. | 1 mm |
| rb max. | 0.3 mm |
| Basic dynamic load rating C | 21.2 kN |
| Basic static load rating C0 | 17 kN |
| Fatigue load limit Pu | 0.71 kN |
| Attainable speed for grease lubrication | 14500 r/min |
| Ball diameter Dw | 9.525 mm |
| Number of balls z | 24 |
| Preload class A GA | 195 N |
| Static axial stiffness, preload class A | 141 N/µm |
| Preload class B GB | 590 N |
| Static axial stiffness, preload class B | 214 N/µm |
| Preload class C GC | 1170 N |
| Static axial stiffness, preload class C | 281 N/µm |
| Calculation factor f | 1.19 |
| Calculation factor f1 | 0.99 |
| Calculation factor f2A | 1 |
| Calculation factor f2B | 1.04 |
| Calculation factor f2C | 1.07 |
| Calculation factor fHC | 1 |
| Calculation factor e | 0.68 |
| Calculation factor (single, tandem) Y2 | 0.87 |
| Calculation factor (single, tandem) Y0 | 0.38 |
| Calculation factor (single, tandem) X2 | 0.41 |
| Calculation factor (back-to-back, face-to-face) Y1 | 0.92 |
| Calculation factor (back-to-back, face-to-face) Y2 | 1.41 |
| Calculation factor (back-to-back, face-to-face) Y0 | 0.76 |
| Calculation factor (back-to-back, face-to-face) X2 | 0.67 |
| Mass bearing | 0.36 kg |
