Home > Angular contact ball bearings > S71916 CB/P4A SKF Attainable speed for grease lubrication 16000 r/min 80x110x16mm Angular contact ball bearings
S71916 CB/P4A SKF Attainable speed for grease lubrication 16000 r/min 80x110x16mm  Angular contact ball bearings

S71916 CB/P4A SKF Attainable speed for grease lubrication 16000 r/min 80x110x16mm Angular contact ball bearings

Bearing numberS71916 CB/P4ASize (mm)80x110x16BrandSKFBore Diameter (mm)80Outer Diameter (mm)110Width (mm)16d80 mmD110 mmB16 mmC16 mmd190.7 mmd289.2 mmr1 min.1 mmr2 min.1 mmr3 min.0.6 mmr4 min.0.6 mmD1102.2 mmD2102.2 mmda min.84.6 mmDa max.105 mmdb min84.6 mmra max.1 mmrb max.0.6 mmdh91.7 mmDb max106.8 mmWeight0.38 KgBasic dynamic load rating (C)15.…
Contact Us Now !

Product description

S71916 CB/P4A SKF Attainable speed for grease lubrication 16000 r/min 80x110x16mm Angular contact ball bearings

Bearing numberS71916 CB/P4A
Size (mm)80x110x16
BrandSKF
Bore Diameter (mm)80
Outer Diameter (mm)110
Width (mm)16
d80 mm
D110 mm
B16 mm
C16 mm
d190.7 mm
d289.2 mm
r1 min.1 mm
r2 min.1 mm
r3 min.0.6 mm
r4 min.0.6 mm
D1102.2 mm
D2102.2 mm
da min.84.6 mm
Da max.105 mm
db min84.6 mm
ra max.1 mm
rb max.0.6 mm
dh91.7 mm
Db max106.8 mm
Weight0.38 Kg
Basic dynamic load rating (C)15.6 kN
Basic static load rating (C0)14.6 kN
(Grease) Lubrication Speed16 000 r/min
(Oil) Lubrication Speed24 000 r/min
Fatigue load limit (Pu)0.63
d190.7 mm
d289.2 mm
D2102.2 mm
r1,2 min.1 mm
r3,4 min.0.6 mm
a24.9 mm
da min.84.6 mm
da max.90.1 mm
db min.84.6 mm
db max.88.6 mm
Da max.105 mm
Db max.106.8 mm
ra max.1 mm
rb max.0.6 mm
Basic dynamic load rating C21.2 kN
Basic static load rating C024 kN
Fatigue load limit Pu0.63 kN
Attainable speed for grease lubrication16000 r/min
Ball diameter Dw6.747 mm
Number of balls z34
Preload class A GA52 N
Static axial stiffness, preload class A49 N/µm
Preload class B GB105 N
Static axial stiffness, preload class B64 N/µm
Preload class C GC310 N
Static axial stiffness, preload class C103 N/µm
Calculation factor f1.13
Calculation factor f11
Calculation factor f2A1
Calculation factor f2B1.02
Calculation factor f2C1.07
Calculation factor fHC1
Calculation factor f09.9
Mass bearing0.4 kg
