S71919 CD/P4A SKF Calculation factor f 1.26 130x95x18mm  Angular contact ball bearings

S71919 CD/P4A SKF Calculation factor f 1.26 130x95x18mm Angular contact ball bearings

Bearing numberS71919 CD/P4ASize (mm)130x95x18BrandSKFBore Diameter (mm)130Outer Diameter (mm)95Width (mm)18d95 mmD130 mmB18 mmd1105.8 mmd2105.8 mmD2122.18 mmr1,2 - min.1.1 mmr3,4 - min.0.6 mma24.1 mmda - min.101 mmda - max.105.2 mmdb - min.101 mmdb - max.105.2 mmDa - max.124 mmDb - max.126 mmra - max.1 mmrb - max.0.6 mmBasic dynamic load rating - C…
Contact Us Now !

Product description

S71919 CD/P4A SKF Calculation factor f 1.26 130x95x18mm Angular contact ball bearings

Bearing numberS71919 CD/P4A
Size (mm)130x95x18
BrandSKF
Bore Diameter (mm)130
Outer Diameter (mm)95
Width (mm)18
d95 mm
D130 mm
B18 mm
d1105.8 mm
d2105.8 mm
D2122.18 mm
r1,2 – min.1.1 mm
r3,4 – min.0.6 mm
a24.1 mm
da – min.101 mm
da – max.105.2 mm
db – min.101 mm
db – max.105.2 mm
Da – max.124 mm
Db – max.126 mm
ra – max.1 mm
rb – max.0.6 mm
Basic dynamic load rating – C49.4 kN
Basic static load rating – C055 kN
Fatigue load limit – Pu2.2 kN
Limiting speed for grease lubrication9000 r/min
Ball – Dw11.112 mm
Ball – z28
Calculation factor – f016.4
Preload class A – GA190 N
Preload class B – GB380 N
Preload class C – GC760 N
Preload class D – GD1520 N
Calculation factor – f1.26
Calculation factor – f1
Calculation factor – f2A1
Calculation factor – f2B1.04
Calculation factor – f2C1.09
Calculation factor – f2D1.15
Calculation factor – fHC1
Preload class A101 N/micron
Preload class B139 N/micron
Preload class C198 N/micron
Preload class D291 N/micron
d1105.8 mm
d2105.8 mm
D2122.18 mm
r1,2 min.1.1 mm
r3,4 min.0.6 mm
da min.101 mm
da max.105.2 mm
db min.101 mm
db max.105.2 mm
Da max.124 mm
Db max.126 mm
ra max.1 mm
rb max.0.6 mm
Basic dynamic load rating C49.4 kN
Basic static load rating C055 kN
Fatigue load limit Pu2.2 kN
Attainable speed for grease lubrication9000 r/min
Ball diameter Dw11.112 mm
Number of balls z28
Preload class A GA190 N
Static axial stiffness, preload class A101 N/µm
Preload class B GB380 N
Static axial stiffness, preload class B139 N/µm
Preload class C GC760 N
Static axial stiffness, preload class C198 N/µm
Preload class D GD1520 N
Static axial stiffness, preload class D291 N/µm
Calculation factor f1.26
Calculation factor f11
Calculation factor f2A1
Calculation factor f2B1.04
Calculation factor f2C1.09
Calculation factor f2D1.15
Calculation factor fHC1
Calculation factor f016.4
Mass bearing0.6 kg
