S71926 ACD/P4A SKF 180x130x24mm  Number of balls z 27 Angular contact ball bearings

S71926 ACD/P4A SKF 180x130x24mm Number of balls z 27 Angular contact ball bearings

Bearing numberS71926 ACD/P4ASize (mm)180x130x24BrandSKFBore Diameter (mm)180Outer Diameter (mm)130Width (mm)24d130 mmD180 mmB24 mmd1145.4 mmd2145.4 mmD2168.25 mmr1,2 - min.1.5 mmr3,4 - min.0.6 mma48.3 mmda - min.137 mmda - max.144.8 mmdb - min.137 mmdb - max.144.8 mmDa - max.173 mmDb - max.176 mmra - max.1.5 mmrb - max.0.6 mmBasic dynamic load rati…
Contact Us Now !

Product description

S71926 ACD/P4A SKF 180x130x24mm Number of balls z 27 Angular contact ball bearings

Bearing numberS71926 ACD/P4A
Size (mm)180x130x24
BrandSKF
Bore Diameter (mm)180
Outer Diameter (mm)130
Width (mm)24
d130 mm
D180 mm
B24 mm
d1145.4 mm
d2145.4 mm
D2168.25 mm
r1,2 – min.1.5 mm
r3,4 – min.0.6 mm
a48.3 mm
da – min.137 mm
da – max.144.8 mm
db – min.137 mm
db – max.144.8 mm
Da – max.173 mm
Db – max.176 mm
ra – max.1.5 mm
rb – max.0.6 mm
Basic dynamic load rating – C87.1 kN
Basic static load rating – C0102 kN
Fatigue load limit – Pu3.4 kN
Limiting speed for grease lubrication6700 r/min
Ball – Dw15.875 mm
Ball – z27
Calculation factor – e0.68
Calculation factor – Y20.87
Calculation factor – Y00.38
Calculation factor – X20.41
Calculation factor – Y10.92
Calculation factor – Y21.41
Calculation factor – Y00.76
Calculation factor – X20.67
Preload class A – GA540 N
Preload class B – GB1080 N
Preload class C – GC2160 N
Preload class D – GD4320 N
Calculation factor – f1.25
Calculation factor – f10.98
Calculation factor – f2A1
Calculation factor – f2B1.04
Calculation factor – f2C1.08
Calculation factor – f2D1.14
Calculation factor – fHC1
Preload class A325 N/micron
Preload class B427 N/micron
Preload class C570 N/micron
Preload class D780 N/micron
d1145.4 mm
d2145.4 mm
D2168.25 mm
r1,2 min.1.5 mm
r3,4 min.0.6 mm
da min.137 mm
da max.144.8 mm
db min.137 mm
db max.144.8 mm
Da max.173 mm
Db max.176 mm
ra max.1.5 mm
rb max.0.6 mm
Basic dynamic load rating C87.1 kN
Basic static load rating C0102 kN
Fatigue load limit Pu3.45 kN
Attainable speed for grease lubrication6700 r/min
Ball diameter Dw15.875 mm
Number of balls z27
Preload class A GA540 N
Static axial stiffness, preload class A325 N/µm
Preload class B GB1080 N
Static axial stiffness, preload class B427 N/µm
Preload class C GC2160 N
Static axial stiffness, preload class C570 N/µm
Preload class D GD4320 N
Static axial stiffness, preload class D780 N/µm
Calculation factor f1.25
Calculation factor f10.98
Calculation factor f2A1
Calculation factor f2B1.04
Calculation factor f2C1.08
Calculation factor f2D1.14
Calculation factor fHC1
Calculation factor e0.68
Calculation factor (single, tandem) Y20.87
Calculation factor (single, tandem) Y00.38
Calculation factor (single, tandem) X20.41
Calculation factor (back-to-back, face-to-face) Y10.92
Calculation factor (back-to-back, face-to-face) Y21.41
Calculation factor (back-to-back, face-to-face) Y00.76
Calculation factor (back-to-back, face-to-face) X20.67
Mass bearing1.58 kg
