Home > Angular contact ball bearings > S7214 CD/P4A SKF 70x125x24mm Static axial stiffness, preload class A 83 N/µm Angular contact ball bearings
S7214 CD/P4A SKF 70x125x24mm  Static axial stiffness, preload class A 83 N/µm Angular contact ball bearings

S7214 CD/P4A SKF 70x125x24mm Static axial stiffness, preload class A 83 N/µm Angular contact ball bearings

Bearing numberS7214 CD/P4ASize (mm)70x125x24BrandSKFBore Diameter (mm)70Outer Diameter (mm)125Width (mm)24d70 mmD125 mmB24 mmC24 mma25 mmd187.9 mmd287.9 mmr1 min.1.5 mmr2 min.1.5 mmr3 min.0.6 mmr4 min.0.6 mmD1107.1 mmD2110.3 mmda min.79 mmDa max.116 mmdb min79 mmra max.1.5 mmrb max.0.6 mmdh91.6 mmDb max120.8 mmWeight1.1 KgBasic dynamic load rating …
Contact Us Now !

Product description

S7214 CD/P4A SKF 70x125x24mm Static axial stiffness, preload class A 83 N/µm Angular contact ball bearings

Bearing numberS7214 CD/P4A
Size (mm)70x125x24
BrandSKF
Bore Diameter (mm)70
Outer Diameter (mm)125
Width (mm)24
d70 mm
D125 mm
B24 mm
C24 mm
a25 mm
d187.9 mm
d287.9 mm
r1 min.1.5 mm
r2 min.1.5 mm
r3 min.0.6 mm
r4 min.0.6 mm
D1107.1 mm
D2110.3 mm
da min.79 mm
Da max.116 mm
db min79 mm
ra max.1.5 mm
rb max.0.6 mm
dh91.6 mm
Db max120.8 mm
Weight1.1 Kg
Basic dynamic load rating (C)68.9 kN
Basic static load rating (C0)58.5 kN
(Grease) Lubrication Speed11 000 r/min
(Oil) Lubrication Speed18 000 r/min
Fatigue load limit (Pu)2.45
d187.9 mm
d287.9 mm
D2110.3 mm
r1,2 min.1.5 mm
r3,4 min.0.6 mm
da min.79 mm
da max.87.1 mm
db min.79 mm
db max.87.1 mm
Da max.116 mm
Db max.120.8 mm
ra max.1.5 mm
rb max.0.6 mm
Basic dynamic load rating C68.9 kN
Basic static load rating C058.5 kN
Fatigue load limit Pu2.45 kN
Attainable speed for grease lubrication11000 r/min
Ball diameter Dw15.875 mm
Number of balls z16
Preload class A GA260 N
Static axial stiffness, preload class A83 N/µm
Preload class B GB520 N
Static axial stiffness, preload class B112 N/µm
Preload class C GC1040 N
Static axial stiffness, preload class C156 N/µm
Preload class D GD2080 N
Static axial stiffness, preload class D225 N/µm
Calculation factor f1.08
Calculation factor f11
Calculation factor f2A1
Calculation factor f2B1.01
Calculation factor f2C1.03
Calculation factor f2D1.05
Calculation factor fHC1
Calculation factor f014.8
Mass bearing1.13 kg
