Home > Needle roller bearings > SCE610-PP INA Bore 0.375 Inch | 9.525 Millimeter 9.525×14.288×15.875mm Needle roller bearings
SCE610-PP INA Bore 0.375 Inch | 9.525 Millimeter 9.525×14.288×15.875mm  Needle roller bearings

SCE610-PP INA Bore 0.375 Inch | 9.525 Millimeter 9.525×14.288×15.875mm Needle roller bearings

Bearing numberSCE610-PPSize (mm)9.525x14.288x15.875BrandINABore Diameter (mm)9.525Outer Diameter (mm)14.288Width (mm)15.875Fw3/8 inchFw9.525 mmD0.563 inchD14.288 mmC10.625 inchC115.875 mmm0.015 lbs / Weightm7 g / WeightCr1300 lbf / Dynamic load rating (radial)Cr5800 N / Dynamic load rating (radial)C0r1480 lbf / Static load rating (radial)C0r6600 N …
Contact Us Now !

Product description

SCE610-PP INA Bore 0.375 Inch | 9.525 Millimeter 9.525×14.288×15.875mm Needle roller bearings

Bearing numberSCE610-PP
Size (mm)9.525×14.288×15.875
BrandINA
Bore Diameter (mm)9.525
Outer Diameter (mm)14.288
Width (mm)15.875
Fw3/8 inch
Fw9.525 mm
D0.563 inch
D14.288 mm
C10.625 inch
C115.875 mm
m0.015 lbs / Weight
m7 g / Weight
Cr1300 lbf / Dynamic load rating (radial)
Cr5800 N / Dynamic load rating (radial)
C0r1480 lbf / Static load rating (radial)
C0r6600 N / Static load rating (radial)
nG25000 1/min / Limiting speed
nB0.001 1/min / Reference speed
Product Group – BDIB04144
CategoryNeedle Non Thrust Roller Bearings
BDI Inventory0.0
Manufacturer NameSCHAEFFLER GROUP
Minimum Buy QuantityN/A
Weight / Kilogram0.008
EAN4012802605365
Rolling ElementNeedle Roller Bearing
ComponentRoller Assembly with Outer Ring – No Inner Ring
Enclosure2 Seals
Self AligningNo
RetainerYes
Number of Rows of RollersSingle Row
SeparableNo
Closed EndNo
Inch – MetricInch
RelubricatableNo
Thrust BearingNo
Long Description3/8" Bore; 9/16" Outside Diameter; 5/8" Width; Needle Roller Bearing; Roller Assembly with Outer Ring – No Inner Ring; 2 Seals Enclosure; No Self Aligning; Yes Retainer; Single Row of Rollers; No Separable; No Closed EndNo Relubricatable
Other Features2 Rib Outer Ring | Drawn Cup Bearing | Steel Cage
Category – BDINeedle Non Thrust Roller Bearing
UNSPSC31171512
Harmonized Tariff Code8482.40.00.00
NounBearing
Keyword StringNeedle
Manufacturer URLhttp://www.ina.com
Manufacturer Item NumberSCE610PP
Weight / LBS0.015
Outside Diameter0.563 Inch | 14.3 Millimeter
Width0.625 Inch | 15.875 Millimeter
Bore0.375 Inch | 9.525 Millimeter
