Home > Needle roller bearings > SCE67-PP INA 9.525×14.288×11.112mm Minimum Buy Quantity N/A Needle roller bearings
SCE67-PP INA 9.525×14.288×11.112mm  Minimum Buy Quantity N/A Needle roller bearings

SCE67-PP INA 9.525×14.288×11.112mm Minimum Buy Quantity N/A Needle roller bearings

Bearing numberSCE67-PPSize (mm)9.525x14.288x11.112BrandINABore Diameter (mm)9.525Outer Diameter (mm)14.288Width (mm)11.112Fw3/8 inchFw9.525 mmD0.563 inchD14.288 mmC10.438 inchC111.112 mmm0.026 lbs / Weightm12 g / WeightCr650 lbf / Dynamic load rating (radial)Cr2900 N / Dynamic load rating (radial)C0r610 lbf / Static load rating (radial)C0r2700 N / …
Contact Us Now !

Product description

SCE67-PP INA 9.525×14.288×11.112mm Minimum Buy Quantity N/A Needle roller bearings

Bearing numberSCE67-PP
Size (mm)9.525×14.288×11.112
BrandINA
Bore Diameter (mm)9.525
Outer Diameter (mm)14.288
Width (mm)11.112
Fw3/8 inch
Fw9.525 mm
D0.563 inch
D14.288 mm
C10.438 inch
C111.112 mm
m0.026 lbs / Weight
m12 g / Weight
Cr650 lbf / Dynamic load rating (radial)
Cr2900 N / Dynamic load rating (radial)
C0r610 lbf / Static load rating (radial)
C0r2700 N / Static load rating (radial)
nG20000 1/min / Limiting speed
CategoryNeedle Non Thrust Roller Bearings
BDI Inventory0.0
Manufacturer NameSCHAEFFLER GROUP
Minimum Buy QuantityN/A
Weight / Kilogram0
EAN4012802070552
Product Group – BDIB04144
Rolling ElementNeedle Roller Bearing
ComponentRoller Assembly with Outer Ring – No Inner Ring
Enclosure2 Seals
Self AligningNo
RetainerYes
Number of Rows of RollersSingle Row
SeparableNo
Closed EndNo
Inch – MetricInch
RelubricatableNo
Thrust BearingNo
Long Description3/8" Bore; 9/16" Outside Diameter; 7/16" Width; Needle Roller Bearing; Roller Assembly with Outer Ring – No Inner Ring; 2 Seals; Not Self Aligning; Retainer; Single Row of Rollers; Not Separable; Not Closed End; Not Relubricatable
Other Features2 Rib Outer Ring | Drawn Cup Bearing | Steel Cage
Category – BDINeedle Non Thrust Roller Bearing
UNSPSC31171512
Harmonized Tariff Code8482.99.65.30
NounRoller Assembly with Outer Ring
Keyword StringBearing Needle
Manufacturer URLhttp://www.ina.com
Manufacturer Item NumberSCE67PP
Weight / LBS0.026
Width0.438 Inch | 11.125 Millimeter
Outside Diameter0.563 Inch | 14.3 Millimeter
Bore0.375 Inch | 9.525 Millimeter

Cross-reference to other manufacturer’s part number

T.P.N. 395 Plain bearings

Basic dynamic load rating (C):610 kN , Weight:33.10 Kg , Angle:7 ° , C1:70 mm
51106 Thrust ball bearings

Basic static load rating (C0):33.5 kN , (Grease) Lubrication Speed:4500 r/min , D1:47 mm , Weight:0.063 Kg , Basic dynamic load rating (C):16.8 kN
R25-9D+X41Z-2 Tapered roller bearings

Width :21mm , Outer Diameter :52mm , B:20 mm , D:52 mm , T:21 mm , d:25 mm
16038 Deep groove ball bearings

Outer Diameter :290mm , d:190 mm , C:31 mm , D:290 mm , Width :31mm , B:31 mm
B86 Needle roller bearings

Basic static load rating (C0):10.1 kN , C:9.52 mm , Fw:12.7 mm , Weight:0.0061 Kg , D:17.462 mm , Basic dynamic load rating (C):6.1 kN
TRU 153320 Cylindrical roller bearings

Basic dynamic load rating (C):10.4 kN , Weight:0.0805 Kg , J:19.5 mm , Basic static load rating (C0):10.4 kN , r min.:0.3 mm
W6200-2RSNR Deep groove ball bearings

C:14.3 mm , Basic dynamic load rating (C):5.11 kN , r min.:0.5 mm , Weight:0.045 Kg
BS2-2316-2CS/VT143 Spherical roller bearings

Calculation factor (Y0):1.8 , Limiting speed:800 r/min , Calculation factor (Y1):1.9 , Calculation factor (e):0.35
W686ZZ Deep groove ball bearings

(Grease) Lubrication Speed:48000 r/min , Weight:0.0018 Kg , Basic dynamic load rating (C):1.1 kN , Basic static load rating (C0):0.44 kN
123073X/123120XH Tapered roller bearings

Weight:2.35 Kg , L:8 mm , R:2.5 mm , J:126.2 mm , da:90 mm
