Home > Needle roller bearings > SCE78 INA 11.112×15.875×12.7mm EAN 4012802134735 Needle roller bearings
SCE78 INA 11.112×15.875×12.7mm  EAN 4012802134735 Needle roller bearings

SCE78 INA 11.112×15.875×12.7mm EAN 4012802134735 Needle roller bearings

Bearing numberSCE78Size (mm)11.112x15.875x12.7BrandINABore Diameter (mm)11.112Outer Diameter (mm)15.875Width (mm)12.7Fw7/16 inchFw11.112 mmD0.625 inchD15.875 mmC0.5 inchC12.7 mmm0.016 lbs / Weightm7 g / WeightCr1430 lbf / Dynamic load rating (radial)Cr6400 N / Dynamic load rating (radial)C0r1750 lbf / Static load rating (radial)C0r7800 N / Static l…
Contact Us Now !

Product description

SCE78 INA 11.112×15.875×12.7mm EAN 4012802134735 Needle roller bearings

Bearing numberSCE78
Size (mm)11.112×15.875×12.7
BrandINA
Bore Diameter (mm)11.112
Outer Diameter (mm)15.875
Width (mm)12.7
Fw7/16 inch
Fw11.112 mm
D0.625 inch
D15.875 mm
C0.5 inch
C12.7 mm
m0.016 lbs / Weight
m7 g / Weight
Cr1430 lbf / Dynamic load rating (radial)
Cr6400 N / Dynamic load rating (radial)
C0r1750 lbf / Static load rating (radial)
C0r7800 N / Static load rating (radial)
nG21900 1/min / Limiting speed
nB15200 1/min / Reference speed
CategoryNeedle Non Thrust Roller Bearings
BDI Inventory0.0
Manufacturer NameSCHAEFFLER GROUP
Minimum Buy QuantityN/A
Weight / Kilogram0.01
EAN4012802134735
Product Group – BDIB04144
Rolling ElementNeedle Roller Bearing
ComponentRoller Assembly with Outer Ring – No Inner Ring
EnclosureOpen
Self AligningNo
RetainerYes
Number of Rows of RollersSingle Row
SeparableNo
Closed EndNo
Inch – MetricInch
RelubricatableNo
Thrust BearingNo
Long Description7/16" Bore; 5/8" Outside Diameter; 1/2" Width; Needle Roller Bearing; Roller Assembly with Outer Ring – No Inner Ring; Open; Not Self Aligning; Retainer; Single Row of Rollers; Not Separable; Not Closed End; Not Relubricatable
Other Features2 Rib Outer Ring | Drawn Cup Bearing | Steel Cage
Category – BDINeedle Non Thrust Roller Bearing
UNSPSC31171512
Harmonized Tariff Code8482.99.65.30
NounRoller Assembly with Outer Ring
Keyword StringBearing Needle
Manufacturer URLhttp://www.ina.com
Manufacturer Item NumberSCE78
Weight / LBS0.016
Bore0.438 Inch | 11.125 Millimeter
Outside Diameter0.625 Inch | 15.875 Millimeter
Width0.5 Inch | 12.7 Millimeter
