SDM20 KOYO W 1.6 mm 20x32x30.5mm  Linear bearings

SDM20 KOYO W 1.6 mm 20x32x30.5mm Linear bearings

Bearing numberSDM20Size (mm)20x32x30.5BrandKOYOBore Diameter (mm)20Outer Diameter (mm)32Width (mm)30.5Fw20 mmD32 mmB30.5 mmD130.5 mmL42 mmW1.6 mmWeight0.092 KgBasic dynamic load rating (C)590 kN Cross-reference to other manufacturer's part number T-H247549/H247510 Tapered roller bearingsC:90.488 mm , d:234.95 mm , Width :112.712mm , D:384.175 mm , …
Contact Us Now !

Product description

SDM20 KOYO W 1.6 mm 20x32x30.5mm Linear bearings

Bearing numberSDM20
Size (mm)20x32x30.5
BrandKOYO
Bore Diameter (mm)20
Outer Diameter (mm)32
Width (mm)30.5
Fw20 mm
D32 mm
B30.5 mm
D130.5 mm
L42 mm
W1.6 mm
Weight0.092 Kg
Basic dynamic load rating (C)590 kN

Cross-reference to other manufacturer’s part number

T-H247549/H247510 Tapered roller bearings

C:90.488 mm , d:234.95 mm , Width :112.712mm , D:384.175 mm , T:112.712 mm , B:112.712 mm
51144 M Thrust ball bearings

Basic static load rating (C0):784 kN , Basic dynamic load rating (C):174 kN , Weight:4.6 Kg , (Grease) Lubrication Speed:1454 r/min , D1:223 mm
C2218M Spherical roller bearings

D1:143.6 mm , Basic static load rating (C0):380 kN , Basic dynamic load rating (C):282 kN , Weight:3.62 Kg
2220-K+H320 Self aligning ball bearings

Basic static load rating (C0):40.5 kN , B1:71 mm , Weight:6.6 Kg , B2:21 mm , Basic dynamic load rating (C):75 kN , D1:130 mm
SL182992 Cylindrical roller bearings

B:95 mm , C:95 mm , Outer Diameter :620mm , Width :95mm , d:460 mm , D:620 mm
21312 Spherical roller bearings

Weight:2.1 Kg , Basic dynamic load rating (C):208 kN , (Grease) Lubrication Speed:4819.5 r/min , Basic static load rating (C0):235 kN
23144A2XK Cylindrical roller bearings

(Oil) Lubrication Speed:1800 r/min , Calculation factor (e):0.34 , Calculation factor (Y0):1.93 , (Grease) Lubrication Speed:1500 r/min , Calculation factor (Y1):1.98
T94W Thrust roller bearings

R:0.8 mm , D:48.021 mm , T:15.088 mm , d:24.054 mm , Width :15.088mm , Outer Diameter :48.021mm
AST40 7570 Plain bearings

OD Chamfer Length (Co):1.800 , ID Chamfer Length (Ci):0.600 , Material:Steel shell with PTFE / Polymer Fiber lining , ID Chamfer Angle (B deg.):45
SCF25ES Plain bearings

Weight:0.53 Kg , B:20 mm , Angle:7 ° , Basic dynamic load rating (C):48 kN , C1 max:24 mm
