SI50ES AST Rod End Width (d2) 112.000  Plain bearings

SI50ES AST Rod End Width (d2) 112.000 Plain bearings

Bearing numberSI50ESBrandASTBore Diameter (mm)50Width (mm)35Bearing Type - steel-on-steelsteelonsteelBore Dia (d)50.0000Width (B)35.0000Radius (min) (rs)0.600Dynamic Load Rating (Cr)156.000Static Load Rating (Cor)290.000Spherical Diameter (dk or Dk)66.000Mis-alignment Angle (a deg.)6Thread Length (l1)68.000Bore Center to End of Rod (h)160.000Rod Ov…
Contact Us Now !

Product description

SI50ES AST Rod End Width (d2) 112.000 Plain bearings

Bearing numberSI50ES
BrandAST
Bore Diameter (mm)50
Width (mm)35
Bearing Type – steel-on-steelsteelonsteel
Bore Dia (d)50.0000
Width (B)35.0000
Radius (min) (rs)0.600
Dynamic Load Rating (Cr)156.000
Static Load Rating (Cor)290.000
Spherical Diameter (dk or Dk)66.000
Mis-alignment Angle (a deg.)6
Thread Length (l1)68.000
Bore Center to End of Rod (h)160.000
Rod Overall Length (l2)216.000
Rod End Thickness (C1)31.000
Bore Center to Body (l7)57
Thread Size (G)M45 X 3
Rod End Width (d2)112.000
Body Dia. (d3)62.000
Body End Dia. (d4)75.000
Body End Width (l5)20.000
Body End Flats (W)70.000
Weight (g)3.500.00
Material – Body – Carbon steel-zinc plated, Ball – Hardened chrome steel-chrome platedHardened chrome steelchrome plated

Cross-reference to other manufacturer’s part number

SE21201 Angular contact ball bearings

D:1500.000 mm , C:195.000 mm , B:195.000 mm , d:1060.000 mm , Width :195.000mm
AST650 125145140 Plain bearings

Material:Cast bronze with solid lubricant inserts. , OD Chamfer Length (Co):3.000 , ID Chamfer Length (Ci):1.200 , ID Chamfer Angle (B deg.):15
T104 Thrust roller bearings

d:26.289 mm , Width :15.875mm , R:0.8 mm , T:15.875 mm , D:50.8 mm
21315 Spherical roller bearings

Basic dynamic load rating (C):279 kN , (Grease) Lubrication Speed:4284 r/min , Weight:3.75 Kg , Basic static load rating (C0):319 kN
15R1920BP-1 Needle roller bearings

Basic dynamic load rating (C):12.1 kN , Bc:20 mm , Weight:0.013 Kg , Ew:19 mm , Lw:15.8 mm , Fw:15 mm
ALF206-18 Bearing units

S:8 mm , Basic dynamic load rating (C):19.5 kN , Bolt (G):M10 , A2:12 mm , Basic static load rating (C0):11.3 kN , Weight:0.6 Kg
LME20OP Linear bearings

Basic dynamic load rating (C):0.86 kN , Weight:0.091 Kg , D1:30.3 mm , W:1.6 mm , θ:60 mm , L:45 mm
29364 M Thrust roller bearings

D1:393 mm , Weight:75.4 Kg , Basic static load rating (C0):10976 kN , Basic dynamic load rating (C):3283 kN , (Grease) Lubrication Speed:918 r/min , E:53 mm
14123A/14274 Tapered roller bearings

Basic dynamic load rating (C):46.1 kN , Basic static load rating (C0):55 kN , da:44 mm , Calculation factor (Y0):0.86 , Calculation factor (e):0.38 , Db:63 mm
2LA-BNS918CLLBG/GNP42 Angular contact ball bearings

C:18 mm , Angle (α):15 ° , d:90 mm , B:18 mm , D:125 mm
