SIBP16S AST Radius (min) (rs) 0.300  Plain bearings

SIBP16S AST Radius (min) (rs) 0.300 Plain bearings

Bearing numberSIBP16SBrandASTBore Diameter (mm)16Width (mm)21Bearing Type - steel-on-bronzesteelonbronzeBore Dia (d)16.0000Width (B)21.0000Radius (min) (rs)0.300Dynamic Load Rating (Cr)21.000Static Load Rating (Cor)25.000Spherical Diameter (dk or Dk)28.580Mis-alignment Angle (a deg.)15Thread Length (l1)33.000Bore Center to End of Rod (h)64.000Rod O…
Contact Us Now !

Product description

SIBP16S AST Radius (min) (rs) 0.300 Plain bearings

Bearing numberSIBP16S
BrandAST
Bore Diameter (mm)16
Width (mm)21
Bearing Type – steel-on-bronzesteelonbronze
Bore Dia (d)16.0000
Width (B)21.0000
Radius (min) (rs)0.300
Dynamic Load Rating (Cr)21.000
Static Load Rating (Cor)25.000
Spherical Diameter (dk or Dk)28.580
Mis-alignment Angle (a deg.)15
Thread Length (l1)33.000
Bore Center to End of Rod (h)64.000
Rod Overall Length (l2)83.000
Rod End Thickness (C1)15.000
Bore Center to Body (l7)18
Thread Size (G)M16
Rod End Width (d2)38.000
Body Dia. (d3)22.000
Body End Dia. (d4)27.000
Body End Width (l5)8.000
Body End Flats (W)22.000
Weight (g)225.00
Material – Body – Carbon steel-zinc plated, Ball – Hardened chrome steel-chrome plated, LinerBronze

Cross-reference to other manufacturer’s part number

51103V/HR11Q1 Thrust ball bearings

D1:18 mm , r1 min.:0.2 mm , r3 min.:0.5 mm , Basic static load rating (C0):0.57 kN , Weight:0.0068 Kg , Basic dynamic load rating (C):0.71 kN
STF700RV9313g Cylindrical roller bearings

D:930 mm , C:620 mm , Basic dynamic load rating (C):14 800 kN , B:620 mm
FY 1.1/16 TF Bearing units

Housing:
FY 506 M
, Bearing:
YAR 206-101-2F
, Recommended diameter for attachment bolts, mm G:10 mm , Recommended tightening torque for grub screw:4 N·m , End cover:
ECY 206
, Recommended diameter for attachment bolts, inch G:0.375 in
XTGB41510R00 Angular contact ball bearings

Width :64.4mm , d:30 mm , C:64.4 mm , D:130 mm
TL23060CAE4 Spherical roller bearings

(Oil) Lubrication Speed:850 r/min , Calculation factor (Y0):2.7 , Calculation factor (e):0.24 , Calculation factor (Y2):4.2
231/500E Cylindrical roller bearings

(Oil) Lubrication Speed:540 r/min , (Grease) Lubrication Speed:420 r/min , Calculation factor (Y0):2.04 , Calculation factor (e):0.32 , Basic static load rating (C0):13000 kN , Calculation factor (Y1):2.09
TSM 16.1 Plain bearings

Thread (G):M16x1.5 , r min.:0.3 mm , Angle:15 ° , Basic dynamic load rating (C):21 kN , Weight:0.18 Kg , C1:15 mm
21309EK Cylindrical roller bearings

Calculation factor (Y0):2.56 , (Oil) Lubrication Speed:6300 r/min , Calculation factor (e):0.26 , Calculation factor (Y1):2.62 , (Grease) Lubrication Speed:5000 r/min
SDE30 Linear bearings

W:1.85 mm , L:68 mm , Weight:0.34 Kg , Basic dynamic load rating (C):1470 kN
SCW 10 Linear bearings

Weight:0.106 Kg , Basic dynamic load rating (C):0.6 kN , S2:4.3 mm , W:40 mm , T:10 mm
