SIZP7S AST  Bore Center to End of Rod (h) 1.375 Plain bearings

SIZP7S AST Bore Center to End of Rod (h) 1.375 Plain bearings

Bearing numberSIZP7SBrandASTBore Diameter (mm)7.9375Width (mm)11.1Bearing Type - steel-on-bronzesteelonbronzeBore Dia (d)0.3125Width (B)0.4370Radius (min) (rs)0.012Dynamic Load Rating (Cr)1.551Static Load Rating (Cor)1.888Spherical Diameter (dk or Dk)0.625Mis-alignment Angle (a deg.)10Thread Length (l1)0.750Bore Center to End of Rod (h)1.375Rod Ove…
Contact Us Now !

Product description

SIZP7S AST Bore Center to End of Rod (h) 1.375 Plain bearings

Bearing numberSIZP7S
BrandAST
Bore Diameter (mm)7.9375
Width (mm)11.1
Bearing Type – steel-on-bronzesteelonbronze
Bore Dia (d)0.3125
Width (B)0.4370
Radius (min) (rs)0.012
Dynamic Load Rating (Cr)1.551
Static Load Rating (Cor)1.888
Spherical Diameter (dk or Dk)0.625
Mis-alignment Angle (a deg.)10
Thread Length (l1)0.750
Bore Center to End of Rod (h)1.375
Rod Overall Length (l2)1.812
Rod End Thickness (C1)0.344
Thread Size (G) – 5/16-24 UNF5/1624 UNF
Rod End Width (d2)0.875
Body Dia. (d3)0.422
Body End Dia. (d4)0.500
Body End Width (l5)0.187
Body End Flats (W)0.437
Weight (g)36.00
Material – Body – Carbon steel-zinc plated, Ball – Hardened chrome steel-chrome plated, LinerBronze
