SL181860-E INA 300x380x38mm Internal Clearance C0-Medium Cylindrical roller bearings

What's New

Product Catalogs

SL181860-E INA 300x380x38mm Internal Clearance C0-Medium Cylindrical roller bearings

Bearing numberSL181860-ESize (mm)300x380x38BrandINABore Diameter (mm)300Outer Diameter (mm)380Width (mm)38d300 mmD380 mmB38 mmD1350.5 mmd1323.5 mmE360 mmrmin2.1 mms3 mm / Axial displacementm9.79 kg / WeightCr455000 N / Dynamic load rating (radial)C0r840000 N / Static load rating (radial)Cur90000 N / Fatigue limit load. radialnG920 1/min / Limiting …

Product description

SL181860-E INA 300x380x38mm Internal Clearance C0-Medium Cylindrical roller bearings

Bearing number	SL181860-E
Size (mm)	300x380x38
Brand	INA
Bore Diameter (mm)	300
Outer Diameter (mm)	380
Width (mm)	38
d	300 mm
D	380 mm
B	38 mm
D₁	350.5 mm
d₁	323.5 mm
E	360 mm
r_min	2.1 mm
s	3 mm / Axial displacement
m	9.79 kg / Weight
C_r	455000 N / Dynamic load rating (radial)
C_0r	840000 N / Static load rating (radial)
C_ur	90000 N / Fatigue limit load. radial
n_G	920 1/min / Limiting speed
Category	Cylindrical Roller Bearings
BDI Inventory	0.0
Manufacturer Name	SCHAEFFLER GROUP
Minimum Buy Quantity	N/A
Weight / Kilogram	11.795
EAN	4054366321961
Product Group – BDI	B04144
Bore Profile	Straight
Cage Material	None
Precision Class	RBEC 1 \| ISO P0
Number of Rows of Rollers	Single Row
Separable	No
Rolling Element	Cylindrical Roller Bearing
Profile	Complete with Outer and Inner Ring
Snap Ring	No
Internal Clearance	C0-Medium
Retainer	No
Relubricatable	Yes
Inch – Metric	Metric
Other Features	Full Complement \| High Capacity \| 2 Rib Inner Ring \| 1 Rib Outer Ring with Retaining Ring \| Operating Temperature Up to 120 Deg
Long Description	300MM Bore; Straight Bore Profile; 380MM Outside Diameter; 38MM Width; RBEC 1 \| ISO P0; Single Row; Not Separable; No Snap Ring; Relubricatable; C0-Medium Internal Clearance; No Retainer
Category – BDI	Cylindrical Roller Bearing
UNSPSC	31171547
Harmonized Tariff Code	8482.50.00.00
Noun	Bearing
Manufacturer URL	http://www.ina.com
Manufacturer Item Number	SL181860E
Weight / LBS	26.004
Outside Diameter	14.961 Inch \| 380 Millimeter
Width	1.496 Inch \| 38 Millimeter
Bore	11.811 Inch \| 300 Millimeter
