SQD 6 C ISB  l2 max. 8.8 mm Plain bearings

SQD 6 C ISB l2 max. 8.8 mm Plain bearings

Bearing numberSQD 6 CBrandISBOuter Diameter (mm)18D18 mmC6.75 mmd6 mmS18 mmd210 mml1 min.11 mml2 max.8.8 mml3 min.23.5 mmL33.5 mmThread (G)M6x1Angle25 °Weight0.021 KgBasic dynamic load rating (C)3.2 kN Cross-reference to other manufacturer's part number 141107X/141165XGS Tapered roller bearingsdb:160 mm , R:3 mm , F:9.52 mm , da:128 mm , Weight…
Contact Us Now !

Product description

SQD 6 C ISB l2 max. 8.8 mm Plain bearings

Bearing numberSQD 6 C
BrandISB
Outer Diameter (mm)18
D18 mm
C6.75 mm
d6 mm
S18 mm
d210 mm
l1 min.11 mm
l2 max.8.8 mm
l3 min.23.5 mm
L33.5 mm
Thread (G)M6x1
Angle25 °
Weight0.021 Kg
Basic dynamic load rating (C)3.2 kN

Cross-reference to other manufacturer’s part number

141107X/141165XGS Tapered roller bearings

db:160 mm , R:3 mm , F:9.52 mm , da:128 mm , Weight:9.16 Kg , L:8 mm
KBF20-PP Linear bearings

D1:54 mm , Basic dynamic load rating (C):0.88 kN , L:45 mm , H:8 mm , Weight:0.184 Kg , A:43 mm
SL024912 Cylindrical roller bearings

d:60 mm , D:85 mm , Outer Diameter :85mm , C:25 mm , B:25 mm , Width :25mm
3209 Angular contact ball bearings

C:30.2 mm , D:85 mm , d:45 mm , a:40.5 mm , B1:30.2 mm
20232 K Spherical roller bearings

D:290 mm , d:160 mm , Outer Diameter :290mm , C:48 mm , B:48 mm , Width :48mm
2200 Self aligning ball bearings

Precision:A1 , Standard Clearance:C0 , Weight (g):42.00 , Material:52100 Chrome steel (or equivalent)
SI8E Plain bearings

Angle:15 ° , C1 max:6.5 mm , Weight:0.039 Kg , Basic dynamic load rating (C):5.5 kN , Thread (G):M8 , W:13 mm
TL23068CAE4 Spherical roller bearings

Calculation factor (Y2):4.2 , (Oil) Lubrication Speed:710 r/min , Calculation factor (e):0.24 , Calculation factor (Y0):2.8
AST11 WC26 Plain bearings

Housing Counterbore Depth Tolerance (Ha tol.) – +0.2 / -0.2:+0.2 / 0.2 , Housing Counterbore Diameter, Nominal (HD):44.000 , Housing Counterbore Diameter Tolerance (HD tol.):+0.12 / 0 , Material:Bronze shell with PTFE / Fiber lining
1217-K+H217 Self aligning ball bearings

Weight:3.1 Kg , D1:110 mm , B2:19 mm , Basic dynamic load rating (C):36.7 kN , Basic static load rating (C0):19.5 kN
