SQZ 8 C RS ISB D3 24 mm  Plain bearings

SQZ 8 C RS ISB D3 24 mm Plain bearings

Bearing numberSQZ 8 C RSBrandISBd8 mmS110 mmL25 mmL316 mmd212 mmd324 mml1 min.12 mml2 max.16 mmD112.5 mmD216 mmD324 mmL65 mmL132 mmS214 mmThread (G)M8x1.25Angle15 °Weight0.075 KgBasic dynamic load rating (C)3.3 kN Cross-reference to other manufacturer's part number UKP313 Bearing unitsB:65 , f0:13.2 , (Refer.)Unit mass(kg):R1/8 , S:10.8AST20 20…
Contact Us Now !

Product description

SQZ 8 C RS ISB D3 24 mm Plain bearings

Bearing number SQZ 8 C RS
Brand ISB
d 8 mm
S1 10 mm
L2 5 mm
L3 16 mm
d2 12 mm
d3 24 mm
l1 min. 12 mm
l2 max. 16 mm
D1 12.5 mm
D2 16 mm
D3 24 mm
L 65 mm
L1 32 mm
S2 14 mm
Thread (G) M8x1.25
Angle 15 °
Weight 0.075 Kg
Basic dynamic load rating (C) 3.3 kN

Cross-reference to other manufacturer’s part number

UKP313 Bearing units

B:65 , f0:13.2 , (Refer.)Unit mass(kg):R1/8 , S:10.8
AST20 200100 Plain bearings

Lube Hole Dia. (dl):9.500 , ID Chamfer Angle (B deg.):45 , Material:Carbon steel shell with POM plastic liner , ID Chamfer Length (Ci):0.800
AST090 22070 Plain bearings

Bearing Length Tolerance (B tol.) – +0 / -0.40:+0 / 0.40 , ID Chamfer Length (Ci):0.600 , OD Chamfer Length (Co):1.800 , ID Chamfer Angle (B deg.):45 , Material:Wrapped bronze with formed lubrication indents.
TUP1 160.115 Plain bearings

D:165 mm , L:115 mm , f2:0.8 mm , d:160 mm , f1:1.6 mm
T-EE275105/275155 Tapered roller bearings

T:73.817 mm , C:50.005 mm , B:69.85 mm , D:393.7 mm
T-EE923095/923176DG2+A Tapered roller bearings

D:444.5 mm , T:209.55 mm , d:241.3 mm , Width :209.55mm
22216EAKW33 Thrust roller bearings

H:33.000 mm , d:80.000 mm , Bore Diameter :80.000mm , Width :33.000mm , D:140.000 mm , Outer Diameter :140.000mm
NTH-5684 Thrust roller bearings

Outside Diameter:5.207 Inch | 132.258 Millimeter , Overall Height with Aligning Washer:0 Inch | 0 Millimeter , Bore 2:3.505 Inch | 89.027 Millimeter , Height:0.375 Inch | 9.525 Millimeter
RW9248 Thrust roller bearings

d:38 mm , C:48 mm , B:52 mm , D:65 mm
YM3820P Needle roller bearings

Basic dynamic load rating (C):42 kN , Fw:38 mm , Weight:0.082 Kg , C:20 mm , D:48 mm , Basic static load rating (C0):82.8 kN
