TL23034CDE4 NSK Calculation factor (Y2) 4.3 170x260x67mm  Spherical roller bearings

TL23034CDE4 NSK Calculation factor (Y2) 4.3 170x260x67mm Spherical roller bearings

Bearing numberTL23034CDE4Size (mm)170x260x67BrandNSKBore Diameter (mm)170Outer Diameter (mm)260Width (mm)67d170 mmD260 mmB67 mmC67 mmr min.2.1 mmda min.182 mmda max191 mmDa min248 mmDa max.233 mmra max.2 mmWeight13 KgBasic dynamic load rating (C)640 kNBasic static load rating (C0)1090 kN(Grease) Lubrication Speed1 200 r/min(Oil) Lubrication Speed1 …
Contact Us Now !

Product description

TL23034CDE4 NSK Calculation factor (Y2) 4.3 170x260x67mm Spherical roller bearings

Bearing numberTL23034CDE4
Size (mm)170x260x67
BrandNSK
Bore Diameter (mm)170
Outer Diameter (mm)260
Width (mm)67
d170 mm
D260 mm
B67 mm
C67 mm
r min.2.1 mm
da min.182 mm
da max191 mm
Da min248 mm
Da max.233 mm
ra max.2 mm
Weight13 Kg
Basic dynamic load rating (C)640 kN
Basic static load rating (C0)1090 kN
(Grease) Lubrication Speed1 200 r/min
(Oil) Lubrication Speed1 600 r/min
Calculation factor (e)0.23
Calculation factor (Y0)2.8
Calculation factor (Y2)4.3
