TL23036CDKE4 NSK Basic static load rating (C0) 1270 kN 180x280x74mm  Spherical roller bearings

TL23036CDKE4 NSK Basic static load rating (C0) 1270 kN 180x280x74mm Spherical roller bearings

Bearing numberTL23036CDKE4Size (mm)180x280x74BrandNSKBore Diameter (mm)180Outer Diameter (mm)280Width (mm)74d180 mmD280 mmB74 mmC74 mmr min.2.1 mmda min.192 mmda max202 mmDa min268 mmDa max.249 mmra max.2 mmWeight17.1 KgBasic dynamic load rating (C)750 kNBasic static load rating (C0)1270 kN(Grease) Lubrication Speed1 200 r/min(Oil) Lubrication Spee…
Contact Us Now !

Product description

TL23036CDKE4 NSK Basic static load rating (C0) 1270 kN 180x280x74mm Spherical roller bearings

Bearing numberTL23036CDKE4
Size (mm)180x280x74
BrandNSK
Bore Diameter (mm)180
Outer Diameter (mm)280
Width (mm)74
d180 mm
D280 mm
B74 mm
C74 mm
r min.2.1 mm
da min.192 mm
da max202 mm
Da min268 mm
Da max.249 mm
ra max.2 mm
Weight17.1 Kg
Basic dynamic load rating (C)750 kN
Basic static load rating (C0)1270 kN
(Grease) Lubrication Speed1 200 r/min
(Oil) Lubrication Speed1 400 r/min
Calculation factor (e)0.24
Calculation factor (Y0)2.8
Calculation factor (Y2)4.2

Cross-reference to other manufacturer’s part number

AXK1120 Needle roller bearings

outside diameter::5.3150 in , Product Group – BDI:B04144 , bore diameter::3.9370 in , manufacturer upc number::4547359023091 , overall width::0.1575 in
BA 1312 Z Needle roller bearings

Basic dynamic load rating (C):12.4 kN , C:19.05 mm , Basic static load rating (C0):19 kN , Weight:0.022 Kg
EXT212+WB Bearing units

Weight:20.6 Kg , Basic dynamic load rating (C):52.5 kN , T:6 mm , A2:84.8 mm
EXFLE209 Bearing units

Weight:2 Kg , Basic dynamic load rating (C):31.85 kN , Thread (G):R1/8" , A2:58.9 mm
24068EK30 Cylindrical roller bearings

Calculation factor (Y1):1.98 , (Oil) Lubrication Speed:900 r/min , Calculation factor (Y0):1.93 , Calculation factor (e):0.34
TLA 1816 UU Needle roller bearings

Weight:0.0163 Kg , Basic static load rating (C0):11.5 kN , C:16 mm , Basic dynamic load rating (C):8.23 kN
XGB41930 Angular contact ball bearings

C:39 mm , Width :39mm , d:42 mm , Weight:0.724 Kg , B:39 mm , D:77 mm
W 6201 Deep groove ball bearings

Mass bearing:0.034 kg , Fatigue load limit Pu:0.127 kN , Calculation factor f0:12 , Basic static load rating C0:3 kN , Calculation factor kr:0.03
3210 Angular contact ball bearings

Da(max):83 , (Refer.)Mass(kg):0.760 , ra(max):1 , da(max):-
2318K Self aligning ball bearings

Calculation factor (kr):0.05 , Calculation factor (Y1):1.7 , Calculation factor (e):0.37 , Calculation factor (Y0):1.8
