TUF1 08.055 Loyal b1 1 mm Plain bearings

Bearing numberTUF1 08.055BrandCXBore Diameter (mm)8Outer Diameter (mm)10d8 mmD10 mmf10.5 mmf20.4 mmb5.5 mmb11 mmd315 mm Cross-reference to other manufacturer's part number 23936AXK Cylindrical roller bearings(Oil) Lubrication Speed:2500 r/min , Calculation factor (Y1):3.55 , Calculation factor (Y0):3.48 , (Grease) Lubrication Speed:1900 r/min , Cal…

Product description

TUF1 08.055 Loyal b1 1 mm Plain bearings

Bearing number	TUF1 08.055
Brand	CX
Bore Diameter (mm)	8
Outer Diameter (mm)	10
d	8 mm
D	10 mm
f1	0.5 mm
f2	0.4 mm
b	5.5 mm
b1	1 mm
d3	15 mm

Cross-reference to other manufacturer’s part number

23936AXK Cylindrical roller bearings	(Oil) Lubrication Speed:2500 r/min , Calculation factor (Y1):3.55 , Calculation factor (Y0):3.48 , (Grease) Lubrication Speed:1900 r/min , Calculation factor (e):0.19
SF8012 Angular contact ball bearings	d:402.000 mm , C:90.000 mm , B:90.000 mm , D:600.000 mm
16016 Deep groove ball bearings	D:125 mm , Basic static load rating (C0):31 kN , Weight:0.61 Kg , Basic dynamic load rating (C):32 kN , B:14 mm , C:14 mm
206KTD Deep groove ball bearings	Weight:0.245 Kg , Basic dynamic load rating (C):22.2 kN , C:19.99 mm , B:19 mm
RE 15025 Thrust roller bearings	Weight:3.16 Kg , r min.:2 mm , dh:194 mm , Dp:182 mm , ds:164 mm , Basic dynamic load rating (C):76.8 kN
150KBE031+L Tapered roller bearings	Calculation factor (Y2):2.6 , Calculation factor (e):0.39 , (Oil) Lubrication Speed:1400 r/min , Calculation factor (Y0):1.7
B66 Needle roller bearings	C:9.52 mm , Basic dynamic load rating (C):5.15 kN , D:14.288 mm , Weight:0.0048 Kg , Basic static load rating (C0):7.6 kN
AST650 121825 Plain bearings	ID Chamfer Angle (B deg.):15 , Bearing Length Tolerance (B tol.) – -0.10 / -0.30:0.10 / 0.30 , Material:Cast bronze with solid lubricant inserts. , ID Chamfer Length (Ci):1.200 , OD Chamfer Length (Co):2.000
X32206M/Y32206M Tapered roller bearings	Calculation factor (e):0.38 , Basic dynamic load rating (C1):54.3 kN , Basic dynamic load rating (Ca90):9.05 , Basic dynamic load rating (C90):14.1
208KG Deep groove ball bearings	d:40 mm , C:18 mm , D:80 mm , B:18 mm , Weight:0.376 Kg , Basic dynamic load rating (C):36.2 kN
